Table of Motherboard Components
LABEL
1. SoC
2. SW900
3. LED
4. PWR_BTN Power On/Off button
5. DC_IN
6. J1800
7. J1801
8. J1301
9. BAT
10. J1300
11. SD
12. USB2.0
13. HDMI
14. LAN
15. Micro USB Micro USB 2.0 port
LI VA Q1A/ PB0 1A ULTRA TI NY PC USER M ANUAL
10
COMPONENTS
Rockchip® RK3288
Recovery button
Power state LED
Power input port
IO board connector
IO board connector
Motherboard connector
Battery connector
Motherboard connector
Micro SD card slot
Standard USB 2.0 port
HDMI connector
Network connector
