- Page 1 1 L/PB01L APOLLO LAKE Elitegroup Computer Systems Co., LTD. No. 239, Sec. 2, Tiding Blvd., Neihu District, Taipei City, Taiwan (11493) Tel: 02-21621177...
- Page 2 Trademark Recognition Windows 10 is a registered trademark of Microsoft Corp. Other product names used in this manual are the properties of their respective owners and are acknowledged. LIVA Q1L / PB01L MINI PC USER MANUAL...
- Page 3 RF emission limits governing this device. Changes or modifications not expressly approved by the system’s manufacturer could void the user’s authority to operate the equipment. LIVA Q1L / PB01L MINI PC USER MANUAL...
- Page 4 Information technology equipment-Immunity characteristics-Limits and methods of measurement EN 60950 Safety for information technology equipment including electrical business equipment EN 62368 Safety for information technology equipment including electrical business equipment CE marking LIVA Q1L / PB01L MINI PC USER MANUAL...
- Page 5 Do not spill water or any other liquid on your system. • When the system is turned OFF, a small amount of electrical current still flows. Always unplug all power, modem, and network cables from the power outlets before cleaning the system. LIVA Q1L / PB01L MINI PC USER MANUAL...
- Page 6 Nordic Lithium Cautions (for lithium-ion batteries) CAUTION: Danger of explosoin if battery is incorrectly replace only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer’s instructions. LIVA Q1L / PB01L MINI PC USER MANUAL...
- Page 7 This class B digital apparatus meets all requirements of the Canadian Interference-causing Equipment Regulations. Cet appareil numérique de la classe B respecte toutes les exigences du Réglement sur le matériel brouilieur du Canada. LIVA Q1L / PB01L MINI PC USER MANUAL...
-
Page 8: Table Of Contents
TABLE OF CONTENTS Preface Chapter 1 Introducing the PC Introduction............1 Specifications..........2 Front and Rear I/O..........4 Side I/O.............6 Install the VESA Mount........7 Motherboard Components......9 LIVA Q1L / PB01L MINI PC USER MANUAL... - Page 9 Memo LIVA Q1L / PB01L MINI PC USER MANUAL viii...
-
Page 10: Introducing The Pc
Chapter 1 Introducing the PC Introduction ® Thank you for choosing LIVA Q1L / PB01L Mini PC featuring Intel Apollo Lake of great performance and with stylish and flexible de- sign. ® ® ® This mini PC is based on Intel... -
Page 11: Specifications
2 x Giga LAN connectors (10/100/ 1000Mbps) • 1 x HDMI 2.0 port • 1 x Micro SD card slot • 1 x DC port • Power button Button and LED Light • Power LED Light LIVA Q1L / PB01L MINI PC USER MANUAL... - Page 12 • Supports dual display Operation • Windows 10 Pro 64bit System Heatsink • Heatsink and cooling fan Design Operation • 0~+40 Temp Dimension • 74mm x 74mm x 34.6mm Color • Black/Blue LIVA Q1L / PB01L MINI PC USER MANUAL...
-
Page 13: Front And Rear I/O
This is power state LED light. 3. USB 3.2 Gen 1x1 Ports Connect USB 3.2 Gen 1x1 port compatible device 4. USB 2.0 Port Connect your USB 2.0 device to this port. LIVA Q1L / PB01L MINI PC USER MANUAL... - Page 14 You can connect the display device to the HDMI port. 6. Giga LAN Port Connect the RJ-45 jack to the LAN (10/100/1000Mbps) ports for Network connecting. 7. 12V DC_IN Port Connect the DC_IN port to the power adapter. LIVA Q1L / PB01L MINI PC USER MANUAL...
-
Page 15: Side I/O
Side I/O 8. Micro SD card slot This is Micro SD card slot. 9. Security Key hole This is security key hole. LIVA Q1L / PB01L MINI PC USER MANUAL... -
Page 16: Install The Vesa Mount
Install the VESA Mount 1. Mount 4 screws on VESA bracket. 2. Fasten 2 screws under the case. LIVA Q1L / PB01L MINI PC USER MANUAL... - Page 17 3. Hold the case towards the VESA bracket and insert the screws into the holes. 4. Slide the case down until it fixed. LIVA Q1L / PB01L MINI PC USER MANUAL...
-
Page 18: Motherboard Components
Motherboard Components Note: Find AJ1~2 and SCN4~5 on the two motherboards, insert SCN4~5 into AJ1~2 correctly after their alignment. LIVA Q1L / PB01L MINI PC USER MANUAL... - Page 19 Standard USB 3.2 Gen 1x1 ports 10. ASUSB2 Standard USB 2.0 port 11. ASHDMI HDMI connector 12. ASLAN1~2 Network connectors (10/100/1000Mbps) 13. ASD Micro SD card slot 14. AJ1 IO board connector 15. AJ2 IO board connector LIVA Q1L / PB01L MINI PC USER MANUAL...
