Bryant 330JAV Service And Maintenance Procedures Manual

Plus 80 2-stage gas-fired induced-combustion furnaces d series
Hide thumbs Also See for 330JAV:

Advertisement

Table of Contents

NOTE: Read the entire instruction manual before starting the
installation.
This symbol
indicates a change since the last issue.

TABLE OF CONTENTS

SAFETY CONSIDERATIONS .....................................................1
INTRODUCTION ..........................................................................2
PROCEDURE ................................................................................2
CARE AND MAINTENANCE.....................................................2
Cleaning and/or Replacing Air Filter.......................................2
Blower Motor and Wheel.........................................................3
Cleaning Heat Exchanger .........................................................4
Electrical Controls and Wiring.................................................6
WIRING DIAGRAMS...................................................................7
TROUBLESHOOTING .................................................................7
REGISTERED QUALITY SYSTEM
Fig. 1-Model 330JAV Horizontal

SAFETY CONSIDERATIONS

Installing and servicing heating equipment can be hazardous due to
gas and electrical components. Only trained and qualified person-
nel should install, repair, or service heating equipment.
Untrained personnel can perform basic maintenance functions
such as cleaning and replacing air filters. All other operations must
be performed by trained service personnel. When working on
heating equipment, observe precautions in the literature, tags, and
labels attached to or shipped with the unit and other safety
precautions that may apply.
service and
maintenance procedures
PLUS 80 2-STAGE GAS-FIRED
INDUCED-COMBUSTION FURNACES
EFFICIENCY
RATING
CERTIFIED
CERTIFIED
®
A95137
Cancels: SP04-65
Fig. 2-Model 331JAV Downflow
Fig. 3-Model 330JAV Upflow
Follow all safety codes. In the United States, follow all safety
codes including the National Fuel Gas Code (NFGC) NFPA No.
54-1999/ANSI Z223.1-1999. In Canada, refer to the current
edition of the National Standard of Canada CAN/CGA-B149.1-
and .2-M00 Natural Gas and Propane Gas Installation Codes
(NSCNGPIC) and Amendment No. 1. Wear safety glasses and
work gloves. Have fire extinguisher available during start-up and
adjustment procedures and service calls.
-1-
330JAV
331JAV
Series D
SP04-73
11-01
A94086
A94085
