Bryant 330JAV Service And Maintenance Procedures Manual

NOTE: Read the entire instruction manual before performing any
service or maintenance.
This symbol → indicates a change since the last issue.
These procedures are for size 60,000 through 120,000 Btuh units.
Index
SAFETY CONSIDERATIONS..................................................1-2
ELECTROSTATIC DISCHARGE (ESD) PRECAUTIONS
PROCEDURE ...........................................................................2
CARE AND MAINTENANCE..................................................2-7
Air Filter Arrangement..........................................................2-3
Blower Motor and Wheel......................................................3-4
Cleaning Heat Exchanger......................................................4-5
Electrical Controls and Wiring .............................................5-7
Troubleshooting ...................................................................7-10
Unit Wiring Diagram................................................................8
Service Label ............................................................................9
Troubleshooting Guide ...........................................................10
SAFETY CONSIDERATIONS
Installing and servicing heating equipment can be hazardous due to
gas and electrical components. Only trained and qualified person-
nel should install, repair, or service heating equipment.
Untrained personnel can perform basic maintenance functions
such as cleaning and replacing air filters. All other operations must
be performed by trained service personnel. When working on
heating equipment, observe precautions in the literature, tags, and
labels attached to or shipped with the unit and other safety
precautions that may apply.
→
Follow all safety codes. In the United States, follow all safety
codes including the National Fuel Gas Code NFPA No. 54-
1996/ANSI Z223.1-1996. In Canada, refer to the current edition of
the National Standard of Canada CAN/CGA-B149.1- and .2-M95
Natural Gas and Propane Gas Installation Codes and Amendment
No. 1. Wear safety glasses and work gloves. Have fire extinguisher
available during start-up and adjustment procedures and service
calls.
Recognize safety information. This is the safety-alert symbol
When you see this symbol on the furnace and in instructions or
manuals, be alert to the potential for personal injury.
Understand the signal words DANGER, WARNING, and CAU-
TION. These words are used with the safety-alert symbol. DAN-
GER identifies the most serious hazards which will result in severe
personal injury or death. WARNING signifies a hazard which
could result in personal injury or death. CAUTION is used to
identify unsafe practices which would result in minor personal
injury or product and property damage.
service and
maintenance procedures
PLUS 80 2-STAGE GAS-FIRED
INDUCED-COMBUSTION FURNACES
Page
.
—1—
Cancels: SP04-31
Fig. 1—Model 330JAV Horizontal
®
ama
A PP R O VED
R
Fig. 3—Model 330JAV Upflow
330JAV
331JAV
Series B
SP04-49
10-97
A95137
Fig. 2—Model 331JAV
Downflow
A94086
CERTIFICATION OF
MANUFACTURING SITE
A94085
