Xaoc Devices DREZNO Operator's Manual page 6

binary
conversion
converter clock
for clarity, only
four most significant
bits are shown
input saw wave and significance of individual bits
7
6
5
4
gate signals at individual bit outputs
result of inverting the most significant bit (7) only
7
6
5
4
gate signals at individual bit outputs
waveform obtained by inverting all bits
7
6
5
4
gate signals at individual bit outputs
result of leaving only the most significant bit (7)
7
6
5
4
result of inverting bit (6) only
7
6
5
4
replacement of bit (6) with square waveform of
the same freqency as the DAC clock signal
7
6
5
4
6 6
result of leaving three most significant bits (7, 6, 5)
7
6
5
4
result of inverting bit (4) only
7
6
5
4
inversion of bit (4) and omission of bit (7)
7
6
5
4
