1. Introduction
Welcome to the AQUASCOPE 3 leak detection system.
AQUASCOPE 3 is a digital acoustic leak locator with superior crystal
clear sound with simple to use operation. It's light weight with a waist
strap for user comfort. The on board digital leak noise analysis displays
the real leak noise level without effect from ambient sounds. To aid pin
pointing while sounding the leak noise is automatically memorised and
the last 8 reads are available for comparison.
The AQUSCOPE 3 has a filter system which allows the operator to
finely tune the narrow band-pass filter to suppress unwanted
interference and background noise while focusing on the leak noise.
The system has a versatile hand probe for direct sounding and leak
location on soft ground. For the ground microphone or combined
locator system a shielded robust ground microphone (Geophone) with
its high performance sensor is available for pin pointing through hard
surfaces.
1.1. System Components
Depending on which AQUASCOPE 3 system was purchased, the
following configuration is supplied:
All Configuration Types include
Amplifier control unit with waist belt
Stereo Headphones
Connection Cable
Hand probe Locator (see chapter 4)
Hand probe microphone
3 x Probe rods including 1 with a tip
1 x Tripod and magnet
Ground Mic Locator (see chapter 5)
Geophone
T bar handle and rod
Combined Locator
All of the above components.
Pmic Kit
Pocket microphone
3 Probe rods including 1 with tip
Ground plate and magnet (optional)
