The adjustable Ladder Rack will fit all trailers from 48" to 100" wide. Made from high
strength aluminum, your Ladder Rack will never rust and will carry loads up to 500
pounds*
Side mount posts and mounting hardware sold separately.
LR-01 Ladder Rack
Thank you for purchasing this GRIDIRON product
*when distributed evenly
Package Contents
Qty
Part #
Description
2
103081 Rack Corner - right
2
103082 Rack Corner - left
1
PO-72 6 ft crossmember
8
103086 Long Double T-nut
16
103074 Bolt, 5/16-18 x 5/8
1
EY-01
Eyebolt tie-downs - set of 2
