  • Page 1 Owner’s manual Mode d’emploi Manual de instrucciones Istruzioni per l’uso M309 MARINE CD/USB RECEIVER WITH CeNET CONTROL LECTEUR MARINE CD/USB AVEC COMMANDE CeNET RECEPTOR CD/USB MARINO CON CONTROL CeNET LETTORE CD/RICEVITORE USB MARINO CON CONTROLLO CeNET...
  • Page 2 Indvendigt i apparatet er anbragt den her gengivne advarselsmækning, som advarer imod at foretage sådanne indgreb i apparatet, at man kan komme til at udsaætte sig for laserstråling. M309 OBS! Apparaten innehåller laserkomponenten som avger laserstrålning överstigande gränsen för laserklass 1.
  • Page 3 Once you’re registered, we can keep you informed of important product information. Register at www.clarion.com - it’s easy to keep your Clarion product up to date. INFORMATIONS DE L’ENREGISTREMENT DE PRODUITS CLARION Pour les Étas Unis et le Canada seulement Cher client: Nous vous remercions d’avoir acheté...

  • Page 4: Table Of Contents

    Thank you for purchasing this Clarion product. ∗ Please do not use this product on vehicles. ∗ Please read this owner’s manual in its entirety before operating this equipment. ∗ Check the contents of the enclosed warranty card and keep it carefully with this manual.

  • Page 5: Precautions

    EXPRESSLY APPROVED BY THE MANUFACTURER FOR COMPLIANCE COULD VOID THE USER’S AUTHORITY TO OPERATE THE EQUIPMENT. INFORMATION FOR USERS: CHANGES OR MODIFICATIONS TO THIS PRODUCT NOT APPROVED BY THE MANUFACTURER WILL VOID THE WARRANTY AND WILL VIOLATE FCC APPROVAL. M309...

  • Page 6: Flip Down Panel

    6. If the FLIP DOWN PANEL does not open fully, gently open it with your hand. M309 Handling Compact Discs • Compared to ordinary music CDs, CD-R and CD-RW discs are both easily affected by high temperature and humidity and some of CD-R and CD-RW discs may not be played.

  • Page 7: Controls

    • Perform repeat play while in CD/MP3/WMA/ AAC/USB/iPod mode. [SCN] button • Perform scan play for 10 seconds of each track while in CD/MP3/WMA/AAC/USB mode. (UP), • Select folders while in MP3/WMA/AAC/USB mode. [ AUX ] [ AUDIO ] [ DIRECT ] (DN) buttons M309...
  • Page 8 • Commence fast-forward or fast-reverse mode. ] button • Perform preset scan while in the radio mode. • Play or pause a track while in CD/MP3/WMA/ AAC/USB/iPod mode. [Q] (EJECT) button • Press to eject disc. [CD SLOT] • Insert CDs here. M309...

  • Page 9: Dcp

    DCP is an extremely important part. Be careful not to damage it by pressing on it with fingernails, screwdrivers, etc. Note: • If the DCP is dirty, wipe off the dirt with a soft, dry cloth only. M309...

  • Page 10: Remote Control

    ] button to turn the /SOURCE power on and press and hold it (1 sec.) to turn the power off. M309 • Each time the [ pressed, the mode switches in the following order: Radio mode ➜ Satellite mode ➜ CD/MP3/ WMA/AAC mode ➜...
  • Page 11 To cancel, press the [ button again (in radio and satellite modes). • Press to play or pause in CD/MP3/WMA/ AAC, USB/iPod, and CD changer mode. IR-Receiver • Receiver for remote control unit. (Operating range: 30° in all directions) M309...

  • Page 12: Wireless Remote Control Unit Operations

    • Press and hold the button (2 sec.) to store current station in ISR memory (radio mode only). [DISP] button • Press to select the desired display. M309 ● Radio/Satellite Radio modes Signal transmitter [BND] button • Switches reception band.

  • Page 13: Inserting The Battery

    • When replacing the battery, insert properly, with +/– polarities oriented correctly. • Do not subject battery to heat, or dispose of in fire or water. Do not attempt to disassemble the battery. • Dispose of used batteries properly. M309...

  • Page 14: Operations

    ∗ The volume level is from 0 (minimum) to 33 (maximum). Switching the display Press the [DISP] button to select the desired display. M309 Audio Adjustment You can adjust a sound effect or tone quality to your preference. To change audio setting 1.

  • Page 15: Adjusting The Bass

    ∗ The factory default setting is “0”. (Adjustment range: +6 to –6) Note: • During audio adjustment mode, if no operation is performed for more than 10 seconds, this mode can be cancelled and return to previous mode. ] button M309...

  • Page 16: Radio Operations

    FM1 ➜ FM2 ➜ FM3 ➜ AM ➜ FM1... Tuning There are 3 types of tuning mode available, seek tuning, manual tuning and preset tuning. M309 Seek tuning 1. Press the [BND] button and select the desired band (FM or AM).

  • Page 17: Preset Scan

    ● Recalling a station with ISR In any mode, press the [ISR] button to turn on the radio function and tune the selected radio station. “ISR” appears in the display. Press the [ISR] button again to return to the previous mode. ] button M309...

  • Page 18: Sirius Satellite Radio Operations

    1. Press the [DISP] button to select the desired channel label. Channel ➜ Category ➜ Title (Artist) ➜ Composer ➜ Channel... M309 Channel input directly This function allows you to input the channel No. directly. 1. Press and hold the [DISP] button.

  • Page 19: Scan Function

    Press the [ ] or [ ] button number. 4-3. Press and hold the [ ] button. 5. Input a new password. Repeat step 4-1 to 4-3. 6. Input the new password again. Repeat step 4-1 to 4-3. to select a M309...
  • Page 20 ] button 4-2. number. 5. Press and hold the [ ] button. M309 Unskip all channel function This function allows you to unskip the skiped channel. 1. Press and hold the [DISP] button. 2. Press the [x] or [v] button to select “UNSKIP ALL CH”.

  • Page 21: Cd/Mp3/Wma/Aac Operations

    3. Press the [ ] or [ ] button to select the “CD” or “MP3”. • “CD” When playing music CD only. • “MP3” When playing music MP3/WMA/AAC only. 4. When setting is completed, remove the disc and reinsert it. M309...

  • Page 22: Displaying Cd Titles

    “LOADING” appears in the display, the CD enters into the slot, and the play starts. M309 Notes: • Never insert foreign objects into the CD SLOT. • If the CD is not inserted easily, there may be another CD in the mechanism or the unit may require service.

  • Page 23: Selecting A Track

    ● To cancel play 1. Press the operating button previously selected. ∗ The various play mode is canceled and the various play off mode appears in the display for 2 seconds. ] button, the ] button to play. M309...

  • Page 24: Operations Common To Each Mode

    2-1. Select “CONTRAST”. 3-1. Press the [ ] or [ ] button to adjust the contrast. M309 ● Displaying the settings The number of indicator of this unit decreases, you can see the state of current settings at any operation mode.
  • Page 25 1. Press and hold the [DISP] button (1 sec.). 2. Select “AUX SENS”. 3. Press the [ ] or [ ] button to select “HIGH”, “MID” or “LOW”. Note: • When AUX mode is selected, AUX IN sensitivity can be set. M309...

  • Page 26: Accessories

    For information regarding supported portable audio players, consult your nearest Clarion dealer, or visit Clarion’s website. • Insert and remove a USB memory/MTP device only when the device is not being accessed. Connecting or disconnecting...
  • Page 27 USB/MTP mode is selected, since it may result in loss or damage to data on the USB memory/MTP device. Always backup and save important data on your computer. 2. Remove the USB memory/MTP device from the USB cable. M309...

  • Page 28: Ipod Operations

    • The unit will not operate, or may operate improperly with unsupported versions. • For a list of compatible Apple iPod unit with the this model, please contact your Clarion dealer or www.clarion.com. • “Made for iPod” means that an electronic...
  • Page 29 ] and [ ] buttons to select a ] or [ ] button to switch ] button. ] button to switch between ] or [ ] button to select the ] and [ buttons to M309...
  • Page 30 This unit supports the display of title information transmitted from a connected iPod. • Character code information is UTF-8; displayable characters include English alphanumerics, some symbols, and some umlaut characters. • Unsupported characters will be replaced by asterisks (*). M309...

  • Page 31: Xm Satellite Radio Operations

    This unit can control the following satellite radio receivers: • XM Satellite Interface Adapter (Mini-Tuner Included) : CNP2000UC Clarion cable for CNP2000UC : CNPCLA1 Note: • XM and the XM logos are trademarks of XM Satellite Radio Inc. Selecting a Satellite Radio mode 1.
  • Page 32 Press and hold the [ ] button (1 sec.) to select the preset scan mode. And start the preset scanning. M309 ● Category scan (CAT SCN) In a category scan, broadcast channels in the same category as the current channel are selected about every 10 seconds.

  • Page 33: Cd Changer Operations

    The disc random play selects and plays individual tracks or discs automatically in no particular order. This function continues automatically until it is cancelled. 1. Press and hold the [RDM] button (1 sec.). ● To cancel play 1. Press the operating button previously selected. M309...

  • Page 34: Troubleshooting

    DCP or main unit connectors are dirty. No sound heard The speaker protection circuit is operating. M309 Cause Replace with a fuse of the same amperage. If the fuse blows again, consult your store of purchase. Consult your store of purchase.
  • Page 35 Disconnect the device and reconnect. If the device is still not recognized, try replacing with a different device. Disconnect the device and reconnect. Try reversing the connection direction of the device (usually the brand name surface should be facing left). Replace with a new device. M309...

  • Page 36: Error Displays

    If an error display other than the ones described above appears, press the reset button. If the problem persists, turn off the power and consult your store of purchase. M309 Cause This is a failure of CD deck’s mechanism and consult your store of purchase.

  • Page 37: Specifications

    1-3/4" (Width) ✕ 4-5/16" (Height) ✕ 7/16" (Depth) [44 (W) ✕ 113 (H) ✕ 11 (D) mm] Power Output : 21 W RMS x 4 Channels at 4 Ω and 1 % THD+N Signal to Noise Ratio: 91 dBA (reference: 1 W into 4 Ω) M309...

  • Page 38: Others

    Microsoft may include a revocation list with the licenses. Content owners may require you to upgrade WMDRM to access their content. If you decline an upgrade, you will not be able to access content that requires the upgrade. M309...
  • Page 39 Clarion Co., Ltd. PE-3163B All Rights Reserved. Copyright © 2009: Clarion Co., Ltd. 2009/02 280-8772-00 Printed in Philippines / Imprimé aux Philippines / Impreso en Filipinas / Stampato nelle Filippine...
