1.4 SPECIFICATIONS

:
SIZE
Display/Processor (including mating connector assembly)
3.37 inches (8.56 centimeters) high
3.37 inches (8.56 centimeters) wide
11.33 inches (28.78 centimeters) deep
Antenna
1.00 inches (2.54 centimeters) high
3.45 inches (8.76 centimeters) wide
6.85 inches (17.40 centimeters) deep
:
WEIGHT
Display/Processor
2.9 lb (1.3 kg)
Antenna (without doubler)
0.84 lb (0.38 kg)
:
TEMPERATURE
Display/Processor
-20 to +55 degrees Celsius (-4 to +131 degrees Fahrenheit)
Antenna
-55 to +70 degrees Celsius (-67 to +158 degrees Fahrenheit)
:
ALTITUDE
Display/Processor
35,000 feet (Maximum)
Antenna
55,000 feet (Maximum)
:
COOLING
Conduction and Forced Air (Internal Fan) Convection
:
DISPLAY RANGE
25, 50, 100, & 200 nmi
TSO COMPLIANCE
TSO-C110a
RTCA COMPLIANCE
Display/Processor Environmental
DO-160C Category C1-BA(NBM)XXXXXXZ(AB)ABZTZAZE3XX
Display/Processor Software
DO-178B Level D
Antenna
DO-160C Category F2-AC(YCLM)XSFXXXXXXXZXZXXE3XX
POWER REQUIREMENTS
Input voltage: 11 to 32 VDC
Current:
Installation Manual
:
:
:
2.0 A ± 0.5 A @ 12 VDC
0.8 A ± 0.25 A @ 28 VDC
