2.1 INTRODUCTION

Installation must be made by qualified personnel, in conformance with applicable government regulations.
The information furnished is for convenience only.
This section describes the installation of Stormscope Series II Model WX-950, in a step by step procedure.
The installation activities in this section will be performed in the following order:

2.2 UNPACKING AND INSPECTING

The display/processor and antenna are sensitive to electrostatic discharge
(ESD) and may be damaged if not handled correctly. Do not remove protective
covers from electrical connectors during unpacking. Touching an exposed
connector may cause electrostatic damage to equipment.
Carefully unpack the system and note any damage to shipping containers or equipment. Visually inspect
each component for evidence of damage. Compare the equipment received with that noted on the packing
list. Immediately report any missing items or evidence of damage to the carrier making the delivery. To
justify a claim, retain the original shipping container and all packing materials.
Every effort should be made to retain the original shipping containers for storage. If the original containers
are not available, a separate cardboard container should be prepared that is large enough to accommodate
sufficient packing material to prevent movement. The ambient temperature of the storage area should not
fall below -55° C (-65° F) or rise above 70° (158° F).

2.3 PRE-INSTALLATION TEST PROCEDURE

Goodrich Avionics Systems recommends testing each display/processor and antenna immediately upon
receipt. The pre-installation test procedure verifies operation of the system and may save valuable
installation time by detecting hidden damage that may have occurred during shipment.

2.3.1 Equipment Required

a. System components to be tested.
1). WX-950 Display/Processor
2). NY-163 Antenna
b. DC Power Supply: 12 to 28 VDC, 30W, or equivalent (not supplied).
