AXOR Uno
Single lever manual shower mixer for concealed installation with loop handle
Surfaces: chrome___Art. no. : 38626000
product features
· designed to run 1 function
· Connection type: basic set
· Maximum flow rate (at 3 bar): 29 l/min
· ceramic cartridge
· Min. operating pressure: 1 bar
· Max. operating pressure: 10 bar
· Maximum temperature can be adjusted on
installation
Product image
Article Details
Price excl. VAT
Scale drawing
£
320.90-
Page
1 / 4
Advertisement
Related Manuals for Axor Uno
Summary of Contents for Axor Uno
- Page 1 AXOR Uno Single lever manual shower mixer for concealed installation with loop handle Surfaces: chrome___Art. no. : 38626000 Article Details product features Price excl. VAT £ 320.90- · designed to run 1 function · Connection type: basic set · Maximum flow rate (at 3 bar): 29 l/min ·...
- Page 2 AXOR Uno Single lever manual shower mixer for concealed installation with loop handle Surfaces: chrome___Art. no. : 38626000 Flowchart Page 2 / 4...
- Page 3 AXOR Uno Single lever manual shower mixer for concealed installation with loop handle Surfaces: chrome___Art. no. : 38626000 Exploded Drawing Year of production: >10/19 Page 3 / 4...
- Page 4 AXOR Uno Single lever manual shower mixer for concealed installation with loop handle Surfaces: chrome___Art. no. : 38626000 Spare part list Year of production: >10/19 Pos. Art. no. Price handle 93037000 escutcheon Ø 170 mm 95803000 O-Ring 48x3 95508000 flange...
