Summary of Contents for Kvik T531T
- Page 1 T531T Check out easy mounting of your kitchen Aventos Front with integrated handle L03260 L03240 L03250 40 cm 50 cm 60 cm 02-11-2020 0a...
- Page 2 T531T Check out easy mounting of your kitchen Aventos DT34,0*0,000 / 176 (Suspension list) 1 pcs (Side) (Base-top) (Back panel) (Suspension list) 1 pcs 1 pcs 2 pcs 2 pcs ID21563(040-050) / ID21564(060) Euro screw Aventos ID21564 Aventos Push open...
-
Page 3: Side Left
T531T FIG. Side Left 6-5mm deep (Side) FIG. Side Left Aventos Flip up R/L (Side) 02-11-2020 0a... -
Page 4: Side Right
T531T FIG. Side Left Screw flh 4x35 3 pcs (Side) FIG. Side Right 6-5mm deep (Side) 02-11-2020 0a... - Page 5 T531T FIG. Side Right Aventos Flip up R/L (Side) FIG. Side Right Screw flh 4x35 3 pcs (Side) 02-11-2020 0a...
- Page 6 T531T FIG. (Suspension list) (Base-top) NB!!! (Base-top) (Side) FIG. (Back panel) 02-11-2020 0a...
- Page 7 T531T FIG. Screw flh (Side) 3,5x45 mm 4 pcs FIG. Screw flh 3,5x45 mm 4 pcs 02-11-2020 0a...
- Page 8 T531T FIG. Screw flh 3,5x15 mm 4 pcs Angle 45x55x30x2 mm 2 pcs FIG. Push -openw-magnet 1 pcs Euro screw 6,3x11 mm 2 pcs Adjustment 02-11-2020 0a...
- Page 9 T531T FIG. Screw flh 3,5x15 mm 10x5 4 pcs 2 pcs Aventos mounting plate 2 pcs L032*0,mano L032*0, mano Click 02-11-2020 0a...
- Page 10 T531T Adjustment Click Aventos / Aventos Cap Left Cap right 02-11-2020 0a 10 /...
- Page 11 T531T Close the door and press Place plate for magnet on the magnet Remove the protection paper Installation, please read instruction SV12224 SV12224 How to wall mount a cabinet 19-12-2019 1a 02-11-2020 0a 11 /...
