Summary of Contents for Chauvet SX Gobo
-
Page 1: User Manual
SX Gobo™ Snapshot Ok on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Duty Cycle USER MANUAL Chauvet, 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com... -
Page 2: Table Of Contents
... 8 EPLACING OBOS ... 9 OUNTING Orientation ... 9 Rigging ... 9 4. OPERATING INSTRUCTIONS... 9 ...10 ENERAL ROUBLESHOOTING ...11 ECHNICAL UPPORT 5. APPENDIX...11 ...11 ENERAL AINTENANCE ...11 ETURNS ROCEDURE ...12 LAIMS ...12 ECHNICAL PECIFICATIONS SX Gobo Manual 2006-12-11/15:16... -
Page 3: Before You Begin
1. B EFORE What is included 1 x SX Gobo™ EHJ 24V 250W Lamp 7 Replaceable Gobos Warranty Card User Manual Unpacking Instructions Immediately upon receiving a fixture, carefully unpack the carton, check the contents to ensure that all parts are present, and have been received in good condition. Notify the shipper immediately and retain packing material for inspection if any parts appear damaged from shipping or the carton itself shows signs of mishandling. -
Page 4: Safety Instructions
Avoid direct eye exposure to the lamp while it is on. Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. SX Gobo Manual 2006-12-11/15:16... -
Page 5: Introduction
CW rotation Stop CCW rotation Fan cooled Product Overview Hanging Bracket Focusing Lens Lamp Alignment Screw Gobo Speed Knob Gobo Rotation Switch Lamp Access Thumbscrew Lamp Alignment Screw SX Gobo Manual Lamp Alignment Screw Fuse Power Cord Lamp Access Thumbscrew 2006-12-11/15:16... -
Page 6: Setup
Carefully reinsert lamp housing into the fixture. Tighten both thumbscrews Note: It may be necessary to align the lamp after replacement. See the “Lamp Alignment” section on the next page for instructions on how to do this. SX Gobo Manual 2006-12-11/15:16... -
Page 7: Lamp Alignment How-To
Screw the fuse holder back in its place and reconnect power. SX Gobo Manual Lamp alignment screws Even out this plate by turning the lamp alignment screws, prior to lamp optimization. -
Page 8: Replacing Gobos
Note: The two springs indicated in figure C can be used to hold gel inserts or dichroic glass. This is optional, and is not included with the SX Gobo. Replace the top cover. SX Gobo Manual Figure A Figure B... -
Page 9: Mounting
Use the gobo rotation switch to set the direction of rotation (up = clockwise rotation, middle = no rotation, down = counter-clockwise rotation). Turn the focusing lens to focus the beam onto your projection surface. SX Gobo Manual NSTRUCTIONS Hanging Clamp... -
Page 10: General Troubleshooting
If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on the next page. -
Page 11: Technical Support
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 12: Claims
Image size ...40.5 mm Max thickness...4 mm LIGHT SOURCE Lamp... EHJ 24V 250W Lamp PHOTO OPTIC Beam Angle ... 20° THERMAL Maximum ambient temperature...95°F (35°C) ORDERING INFORMATION SX Gobo ... SX-GOBO WARRANTY INFORMATION Warranty ... 1-year limited warranty SX Gobo Manual 2006-12-11/15:16...
