Summary of Contents for Chauvet SX GOBO DMX512
- Page 1 SX Gobo™ Snapshot Ok on Dimmer Outdoor OK Sound Activated DMX512 Master/Slave 115V/230V Switch Replaceable Fuse User Serviceable Duty Cycle USER MANUAL Chauvet, 3000 N 29 Ct, Hollywood, FL 33020 U.S.A. (800) 762-1084 – (954) 929-1115 FAX (954) 929-5560 www.chauvetlighting.com...
-
Page 2: Table Of Contents
ABLE OF ONTENTS 1. BEFORE YOU BEGIN ... 3 ... 3 HAT IS INCLUDED ... 3 NPACKING NSTRUCTIONS AC P ... 3 OWER ... 3 ONTACT ... 4 AFETY NSTRUCTIONS 2. INTRODUCTION ... 5 ... 5 EATURES ... 5 RODUCT VERVIEW 3. -
Page 3: Before You Begin
Earth Ground. Contact Us W o r l d W i d e General Information Technical Support World Wide Web SX Gobo Manual EGIN Chauvet Lighting 3000 North 29 Court Hollywood, FL 33020 voice: 954.929.1115 fax: 954.929.5560 toll free: 800.762.1084... -
Page 4: Safety Instructions
Avoid direct eye exposure to the lamp while it is on. Caution! There are no user serviceable parts inside the unit. Do not open the housing or attempt any repairs yourself. In the unlikely event your unit may require service, please contact CHAUVET at: 954-929-1115. SX Gobo Manual 2006-12-11/15:16... -
Page 5: Introduction
2. I NTRODUCTION Features High-output rotating gobo projector Interchangeable rotating color/gobos 6 metal gobos with 5 dichroic colors + white Dual spring clips for a single dichroic color Adjustable rotation speed 3-position switch: CW rotation Stop CCW rotation Fan cooled Product Overview Hanging Bracket... -
Page 6: Setup
3. S ETUP Lamp You will need to install a lamp prior to the initial operation of the fixture. An 800W halogen lamp is included. Warning! When replacing the lamp, please wait 15 minutes after powering down to allow the unit to cool down! Always disconnect from main power prior to lamp replacement. -
Page 7: Lamp Alignment How-To
Lamp Alignment How-To Often, after a new installation of a lamp, you will find that there is an uneven field of light or what is refered to as a hot spot. This is due to the most intense point of the lamp source not being positioned optimally within the reflector. -
Page 8: Replacing Gobos
Replacing Gobos Open the top cover by removing the six screws indicated in figure A. Remove the retaining spring using a flathead screwdriver (figure B). Remove the gobo and replace with a new gobo. Note: The black side of the gobo should be facing the lamp. -
Page 9: Mounting
Mounting ORIENTATION This fixture may be mounted in any position provided there is adequate room for ventilation. R IG G IN G It is important never to obstruct the fan or vents pathway. Mount the fixture using, a suitable “C” or “O” type clamp. Adjust the angle of the fixture by loosening both knobs and tilting the fixture. -
Page 10: General Troubleshooting
If you still have a problem after trying the above solutions, please contact CHAUVET Technical Support at the location on the next page. -
Page 11: Technical Support
Package must be clearly labeled with a Return Merchandise Authorization Number (RA #). Products returned without an RA # will be refused. Call CHAUVET and request RA # prior to shipping the fixture. Be prepared to provide the model number, serial number and a brief description of the cause for the return. -
Page 12: Claims
Claims Damage incurred in shipping is the responsibility of the shipper; therefore the damage must be reported to the carrier upon receipt of merchandise. It is the customer's responsibility to notify and submit claims with the shipper in the event that a fixture is damaged due to shipping. Any other claim for items such as missing component/part, damage not related to shipping, and concealed damage, must be made within seven (7) days of receiving merchandise.
