PIAGGIO MP3 300 hpe 2020 Manual page 114

Front tire pressure
Rear tyre pressure
Kerb weight
Maximum weight limit
Battery
ENGINE SPECIFICATIONS
Type
Engine capacity
Bore per stroke
Compression ratio
Idle engine speed
Timing system
Valve clearance (cold engine)
Max. power
MAX torque
Transmission
1.7 bar
2.2 bar (2.6 bar with passenger)
225 kg
420 kg
12 V - 10 Ah
Single cylinder 4-stroke
278 cm³
75 X 63 mm
11 ± 0.5: 1
1,700 ± 100 rpm
Four valves, single overhead
camshaft, chain-driven.
Intake: 0.10 mm
Exhaust: 0.15 mm
19.3 kW at 7,750 rpm
26 Nm at 6.500 rpm
CVT expandable pulley variator
with torque server, V-belt, self-
ventilating dry automatic
centrifugal clutch and transmission
housing with forced-circulation air
cooling.
114
