Chauvet ST-1000S User Manual

T roubleshooting
• If the unit is not functional – check the main power supply and for a blown fuse.
• If the unit is functional but the lamp is not on - lamp may need replacing.
• If the unit is not flashing to the music, check the sound sensitivity adjustment.
• If after trying this solution you still have a problem, contact CHAUVET.
Contact Chauvet
USA
Tecnical Assistance: 1-800-762-1084 (954) 929-1115
E-Mail tech@chauvetlighting.com
Caution
Do not touch unit or lamps while its hot.
Never put any objects through the front of the unit.
No user serviceable parts inside, please refer to CHAUVET for service.

Power Connections

The unit is supplied with a power plug appropriate for its voltage and destination. Should any other
connections be required they must be carried out with the following configuration.
Earth = Green/Yellow cable
Neutral = Blue cable
Live = Brown cable
In the USA & Europe, it is required that all plugs are 3-pin type i.e. with Earth/Ground connection.
In the UK, it is required that all mains plugs are fitted with 5A fuses.

Technical Specifications

Power 120V~60Hz AC
120V 35w
Lamp
Part No WSB
Dimensions 200 x 150 x 190mm / 8 x 6 x 7.5in
Weight
. 45kg / 1lbs
User Informtion (Please complete for your records)
Date Purchased: / /
Dealer Stamp:
230V~50Hz AC
230V 35w
Part No WSB2
200 x 150 x 190mm / 8 x 6 x 7.5 in
. 45kg / 1lbs
Serial No: ________________
Model: ST-1000S Techno Strobe 1000S
Techno Strobe 1000S
ST-1000S
User Guide
Please read these instructions carefully before use
W orld-wide Headquarters:
3000 North 29th Ct.
Hollywood, Florida, USA 33020
Tel: +1-954-929-1115 Fax: +1-954-929-5560
www.ChauvetLighting.com
