Power On The Extender; Set Up The Extender; Method 1: Via The Wps Button - TP-Link RE105 User Manual

Chapter 2
2. 1.

Power On the Extender

Plug the extender into an electrical outlet
Power LED turns solid on.
Note: For safety, we suggest that you plug the extender in upright directions as shown below.
2. 2.

Set Up the Extender

There are three ways to connect to the host network: via the WPS button, via a web
browser, or via the Tether app.
2. 2. 1.

Method 1: Via the WPS Button

Use this way if your router has a WPS button. The button might look like one of these:
.
1. Press the WPS button on your host router, and then press the WPS button on the
extender for 1 second within 2 minutes.
Note:
For more information about using WPS button on your host router, please refer to the router's user
guide.
2. Wait until the Signal LED changes from blinking to solid on, indicating successful
connection.
Set Up Internet Connection
near your host router, and then wait until the
Solid On
7
