5.
REMOTE DUTY CYCLE
(IF APPLICABLE)
If using remote setpoint for Precision Spray Control (PSC),
connect input of a 4-20mA analog signal to "4-20mA"
connection to adjust the duty cycle remotely.
6.
POWER UP
THE PANEL
Plug into grounded (115-230 VAC, 1ph.) power source
and turn on power. HMI display will illuminate. To
set spray parameters and for HMI operation, please
refer to section 6 of the owner's manual.
HMI Screen
1750
+
SPRAY CONTROLLER
1750
+
SPRAY CONTROLLER
