Two Frame Stainless Steel Honey Extractor
Instruction Manual
SKU: BEE-V003D
Scan the QR code with your mobile device or follow the link
for helpful videos and specifications related to this product.
https://vivo-us.com/products/bee-v003d
GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST
help@vivo-us.com
www.vivo-us.com
Chat live with an agent!
309-278-5303
Advertisement
Table of Contents
Related Manuals for Vivo BEE-V003D
Summary of Contents for Vivo BEE-V003D
- Page 1 Two Frame Stainless Steel Honey Extractor Instruction Manual SKU: BEE-V003D Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/bee-v003d GET IN TOUCH | Monday-Friday from 7:00am-7:00pm CST help@vivo-us.com...
-
Page 2: Package Contents
WARNING: IMPORTANT SAFETY INFORMATION READ AND FOLLOW ALL SAFETY REQUIREMENTS KEEP THIS MANUAL IN A SAFE AND DRY PLACE FOR FUTURE REFERENCE If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts. -
Page 3: Assembly Steps
ASSEMBLY STEPS STEP 1 Assemble Upper Legs (B) and Lower Legs (C) in one of the two height settings using M8x16 Hex Head Screws (S-C) M8 Washers (S-E) and M8 Lock Washers (S- STEP 2 Mount leg assemblies to Drum (A) using M8x25 Hex Head Screws (S-A) and M8x20 Hex Head Screws (S-B) with M8 Washers (S-E), M8 Lock Washers (S-D) and M8 Plastic Knobs (S-F). - Page 4 STEP 3 Carefully cut the zipties securing the basket to the upper crossbar in Drum (A). Remove the wingnuts from the top of the crossbar and carefully remove the crossbar and basket from Drum (A). STEP 4 Install Honey Gate (F) in Drum (A) and reinstall the basket and crossbar to Drum (A).
- Page 5 STEP 5 Slide Handle (D) onto the shaft on Drum (A). Tighten the security screw and nut on Handle (D) to secure it in place. STEP 6 Place Lids (E) on top of Drum (A). STEP 7 (Optional) For added security, Concrete Anchors (S-G) can be use to secure the extractor to the floor.
- Page 6 OPERATING INSTRUCTIONS STEP 1 Place honey frames in extractor basket. Load both sides to keep extractor balanced as this will reduce any possible shaking. STEP 2 Place lids on extractor and begin turning handle to extract honey. STEP 3 Once the frames have been emptied on one side, remove the frames, turn the frames around, and place them back in the extractor.
-
Page 7: Care And Maintenance
CARE & MAINTENANCE QUICK CLEANING Option 1: Rinse extractor out with cold water from a hose. If available, a pressure washer is very effective. Empty excess water to prevent possible surface rust. Option 2: Place open extractor next to hive. Bees will clean it out and use the materials. - Page 8 AVG. RESPONSE TIME (within office hrs) - 23% within < 15m - 38% within < 30m - 61% within < 1hr - 83% within < 2hr - 92% within < 3hr FOR MORE VIVO PRODUCTS, CHECK OUT OUR WEBSITE AT: www.vivo-us.com...
