Electric three frame stainless steel honey extractor (8 pages)
Summary of Contents for Vivo BEE-V003D
Page 1
Honey Extractor Instruction Manual SKU: BEE-V003D Scan the QR code with your mobile device or follow the link for helpful videos and specifications related to this product. https://vivo-us.com/products/bee-v003d help@vivo-us.com www.vivo-us.com 1-800-371-5654...
Page 2
WARNING: IMPORTANT SAFETY INFORMATION READ AND FOLLOW ALL SAFETY REQUIREMENTS KEEP THIS MANUAL IN A SAFE AND DRY PLACE FOR FUTURE REFERENCE If you do not understand these directions, or if you have any doubts about the safety of the installation, please call a qualified technician. Check carefully to make sure there are no missing or defective parts.
Page 3
PACKAGE CONTENTS 1 (x1) Honey Extractor Drum 2 (x2) Clear Lid 3 (x1) Honey Gate with Lid 4 (x1) Hex Nut (on Honey Gate) 5 (x1) O Ring (Pre-installed on Honey Gate) 6 (x3) 7 (x6) Leg Bolt 8 (x6) Washer 9 (x1) Wing Nut...
Page 4
STEP 2 To install honey gate, remove large hex nut from gate piece. Insert gate through the front side hole and secure backside with hex nut (tighten enough to seal O ring). STEP 3 Slide crank handle onto the shaft and tighten bolt to the flattened shaft area.
Page 5
STEP 4 Place clear lids on top of honey extractor. STEP 5 (Optional) Bolt feet down to floor or surface for added stability (hardware included).
Page 6
OPERATING INSTRUCTIONS 1. Place honey frames in extractor basket. Load both sides to keep extractor balanced as this will reduce any possible shaking. 2. Place lids on extractor and begin turning handle to extract honey. 3. Once the frames have been emptied on one side, remove the frames, turn the frames around, and place them back in the extractor.
Page 7
CARE & MAINTENANCE QUICK CLEANING Option 1: Rinse extractor out with cold water from a hose. If available, a pressure washer is very effective. Empty excess water to prevent possible surface rust. Option 2: Place open extractor next to hive. Bees will clean it out and use the materials.
Page 8
Love your new VIVO setup and want to share? Tag us in your photo! @vivo_us If any parts are received damaged or defective, please contact us. We are happy to replace parts to ensure you have a fully functioning product.
