3.7.2.7 Raid Set Information

To display RAID set information, move the cursor bar to the de-
sired RAID set number, then press the Enter key. The "Raid Set
Information" will appear.
You can only view information for the RAID set in this screen.

3.7.3 Volume Set Function

A volume set is seen by the host system as a single logical de-
vice; it is organized in a RAID level within the controller utiliz-
ing one or more physical disks. RAID level refers to the level of
data performance and protection of a volume set. A volume set
can consume all of the capacity or a portion of the available disk
capacity of a RAID set. Multiple volume sets can exist on a RAID
48
