BIOS CONFIGURATION
•

Migrating

Migration occurs when a disk is added to a RAID set. Migrating
state is displayed in the RAID state area of "The Raid Set
Information" screen when a disk is being added to a RAID set.
Migrating state is also displayed in the associated volume state
area of the "Volume Set Information" which belongs this RAID
set.

3.7.2.4 Activate Incomplete Raid Set

The following screen is used to activate the RAID set after one
of its disk drive was removed in the power off state.
When one of the disk drives is removed in power off state, the
RAID set state will change to "Incomplete State". If user wants
to continue to work while the SAS RAID controller is powered
on, the user can use the "Activate Incomplete Raid Set" option
46
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
Ethernet Configuration
View System Events
Clear Event Buffer
Hardware Monitor
System information
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
I/O Port Addr : 28000000h, F2(Tab): Select Controller, F10: Reboot System
Areca Technology Corporation RAID Controller
Main Menu
Quick Volume/Raid Setup
Raid Set Function
Raid Set Function
Volume Set Function
Physical Drives
Raid System Function
Ethernet Configuration
View System Events
Clear Event Buffer
Hardware Monitor
System information
ArrowKey Or AZ:Move Cursor, Enter: Select, ESC: Escape, L:Line Draw, X: Redraw
Raid Set Function
The Raid Set Information
Create Raid Set
Raid Set Name
Delete Raid Set
Member Disks
Expand Raid Set
Raid State
Activate Raid Set
Total Capacity
Create Hot Spare
Free Capacity
Delete Hot Spare
Min Member Disk Size : 400.0GB
Raid Set Iformation Raid Set Information
Member Disk Channels : .E1S1.E1S2.
Raid Set Function
Create Raid Set
Delete Raid Set
Expand Raid Set
Activate Raid Set
Select Raid Set To Activate
Activate Raid Set
Create Hot Spare
Raid Set
Delete Hot Spare
Raid Set Information
: Raid Set # 00
: 2
: Migrating
: 800.0GB
: 800.0GB
# 00
