- Page 1 Instruction manual for COOKER HOODS Instruction manual for deluxe electronic washing machine Model code: WMi2004 Model code: VIE550BK - VIE550SS Contact Caple on 0844 800 3830 or for spare parts www.4caple.co.uk Contact Caple on 0844 800 3830 or for spare parts www.4caple.co.uk...
- Page 3 The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
- Page 4 CONTENTS Warnings Uses Installation Working Maintenance...
-
Page 5: Installation
VIE550BK Installation indicated on the label placed inside the ap- Place the fixing plate (Fig.1) into the cei- pliance itself. - Page 6 Insert the fixing plate cover from the rod upper part, as per Fig. 3. Hang the appliance to the fixing plate, and secure the plate by using the two screws supplied with the appliance, as shown in Fig. 4. Make the electric connection. Lift the fixing plate cover and secure it with the screws supplied with the applian- ce, as shown in Fig.
- Page 7 Standard configuration WORKING If two cookerhoods-radiocontrol system are installed in the same room or in the immediate vicinity, each system may affect the operation of the other, due to the fact that they have the same code. Therefore it will be necessary to Remote control for cooker hood remote fig.
-
Page 8: Maintenance
An accurate maintenance guarantees good functioning and long-lasting performance. A special care is due to the grease filter. VIE550BK grease filters replacement Remove the lower cylindrical plate as shown in Fig. 7, by pulling it downwards since it is magnetically hold. - Page 9 Fig.6 Fig.1 Fig.2 Fig.7 Fig.6 Fig.8 Fig.3 Fig.4 Fig.7 Fig. 9 Fig. 10 Fig. 9 . 10 ...
