PILOT 300
PR-2301
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep this
manual in a safe place for future reference.
PEARL RIVER LIGHT & ACOUSTICS INDUSTRIAL LTD.
Yingbin Road, Dashi Panyu, Guangzhou, 511430 China
h t t p : / / w w w . p r - l i g h t i n g . c o m

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PILOT 300 and is the answer not in the manual?

Questions and answers

Related Manuals for Pure Reliability PILOT 300

Summary of Contents for Pure Reliability PILOT 300

  • Page 1 PILOT 300 PR-2301 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PEARL RIVER LIGHT & ACOUSTICS INDUSTRIAL LTD.
  • Page 2 PILOT 300 complies to CE norms and standards and uses international protocol DMX 512. PILOT 300 can be used as a stand-alone unit or linked to a controller, so it is suitable for many different applications.

  • Page 3: Safe Usage Of The Projector

    SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. The projector is for Indoor use only, IP20.

  • Page 4: Installing The Projector

    Always ensure that the structure to which you are attaching the projector is secure and is able to support a weight of 18Kg for each PILOT 300. For safety the projector should have a secondary fixing with a safety chain through the holes on the underside of the unit.

  • Page 5: Power Supply - Mains

    DMX IN FROM CONTROLLER TERMINATOR PILOT 300 uses 3-pin XLR plug / socket. If your controller uses 5-pin XLR plug / socket, you should use a conversion cable from 5-pin to 3-pin as shown bellow. 3 PIN PLUG 3 PIN SOCKET...

  • Page 6: Setup Options - Projector Configuration

    DOWN ENTER Each PILOT 300 must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX start address is the channel number from which the projector starts to “listen” to the digital control information being sent out from the controller. The PILOT 300 has 10 channels, so set the No.

  • Page 7: Dmx Control Channel Functions

    DMX CONTROL CHANNEL FUNCTIONS The PILOT 300 uses 10 DMX channels. They are listed in the following table. CHANNEL DMX VALUE DESCRIPTION 0-33 Open / Clear (5-7 for 5 secs.) Soft reset – See Note 34-66 (GLASS) GOBO 1 67-99...

  • Page 8: Maintenance

    MAINTENANCE If the projector’s lens becomes damaged or broken it should be replaced. If the lamp becomes damaged or deformed in any way it must be replaced. If the light from the lamp appears dim this would normally indicate that it is reaching the end of its life and it should be changed at once, old lamps run to the extremity of their life can explode.

  • Page 9: Keeping The Projector Clean

    KEEPING THE PROJECTOR CLEAN To ensure the reliability of the projector it should be kept clean. It is recommended that the fans should be cleaned every 15 days. The lens and dichroic colour filters should also be regularly cleaned to maintain an optimum light output.

  • Page 10: Technical Data

    TECHNICAL DATA VOLTAGES: 100/120/200/220/230/240V AC, 50Hz or 60Hz To Order. POWER CONSUMPTION: 480W @ 220V LAMP: Type : HTI 300W/DX discharge lamp. Colour Temperature: 6500ºK Socket: SFc10-4 Manufacturers Rated Lamp Life: 750 Hours COLOURS: 9 Dichroic colours plus white GOBOS: 7 interchangeable, rotating gobos, with 4 extra supplied as standard.

  • Page 11: Light Output

    LIGHT OUTPUT 3500 lux 870 lux 380 lux 190 lux 100 lux 12º DISTANCE DIAMETER Ø 0m Ø 1.5m Ø 2.1m Ø 3.15m Ø 4.2m Ø 5.25m ELECTRICAL DIAGRAM DC 24V BASE SHUTTER 1 SHUTTER 2 HEAD MOTOR MOTOR PRISM GOBO GOBO FAN 1...
  • Page 12 NOT SHOWN HTD420-3M-140Z 140 TEETH NOTE: You may order all parts of the PILOT 300 besides the table listed above. When ordering please state the exact name and part no.. Repairs must be carried out by a qualified technician. 12/14...
  • Page 13 13/14 pilot300_en.doc...
  • Page 14 PEARL RIVER LIGHT & ACOUSTICS INDUSTRIAL LTD. Yingbin Road, Dashi, Panyu, Guangzhou ,China Post-Code: 511430 TEL: 020-8478-1888 FAX: 020-8478-6023 P/N: 321010041 Last Revision: 12:11:2002 14/14 pilot300_en.doc...
