PILOT 1200 WASH
PR2901
This product manual contains important information about the safe installation
and use of this projector. Please read and follow these instructions carefully
and keep this manual in a safe place for future reference.
PR LIGHTING LTD.
No. 571, Yingbin Road, Dashi Panyu, Guangzhou, 511430 China
http://www.prlighting.com
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pure Reliability Pilot 1200 Wash
Summary of Contents for Pure Reliability Pilot 1200 Wash
- Page 1 PILOT 1200 WASH PR2901 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD.
-
Page 2: Table Of Contents
Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PILOT 1200 WASH is an innovative projector with an elegant housing, which complies to CE norms and standards and uses international protocol DMX 512. -
Page 3: Safe Usage Of The Projector
Always disconnect from the mains, when the device is not in use or before cleaning it or before attempting any maintenance work. If you have any questions, don’t hesitate to consult your dealer or manufacturer. 3/16 Pilot 1200 wash EN.doc... -
Page 4: Installing The Projector
Always ensure that the projector is firmly anchored to avoid vibration and slipping whilst functioning. Always ensure that the structure that you are going to mount the projector is secure and is strong enough to support a weight of PILOT 1200 WASH. WARNING: 1. Unlock the PAN and TILT before the 1 application of projector for safety. -
Page 5: Power Supply – Mains
IMPORTANT It is essential that each projector is correctly earthed and the electrical installation conforms to all relevant standards. Power consumption of the PILOT 1200 WASH is 1380W. CONTROL CONNECTIONS Connection between controller and projector and between one projector and another must be made with 2 corescreened cable, with each core having at least a 0.5mm diameter. -
Page 6: Dmx Terminator
Press the button FUNC , it will return to the upper menu one by one. TO SET THE DMX START ADDRESS Each PILOT 1200 WASH must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX start address is the channel number from which the projector starts to “listen”... -
Page 7: Functions Display
DMX CONTROL CHANNEL DISABLED SET LAMP CONTROL MODE (Default:CTRL) BY CONTROL CHANNEL BY LAMP MENU BY DMX SIGNAL EXISTING OR NOT OPTION MENU SET COLOUR FILTERS (Default : STEP) LINEAR ROTATION DISABLED LINEAR ROTATION ENABLED SET ROTATION OF PAN (Default:OFF) FORWARD ROTATION REVERSE ROTATION SET ROTATION OF TILT (Default:OFF) FORWARD ROTATION REVERSE ROTATION SET PAN&TILT SWAP (Default:OFF) PAN&TILT SWAP OFF PAN&TILT SWAP ON SET DIMMER INVERT(Default:OFF) DIMMER INVERT OFF DIMMER INVERT ON SET ZOOM INVERT (Default:OFF) ZOOM INVERT OFF ZOOM INVERT ON SET CYM INVERT (Default:OFF) CYM INVERT OFF CYM INVERT ON RESET (Default : OFF) DISABLED ENABLED AND LOAD ALL DEFAULTS (CONTINUE) 7/16 Pilot 1200 wash EN.doc... - Page 8 DISPLAY DRIVER PCB Ⅰ 'S TEMPERATURE DISPLAY DRIVER PCB Ⅱ 'S TEMPERATURE DISPLAY PAN&TILT DRIVER PCB'S TEMPERATURE DISPLAY HEAD'S TEMPERATUER RESERVED DISPLAY PROGRAM VERSION DISPLAY MAIN PCB'S PROGRAM VER. DISPLAY MOTOR DRIVER PCB Ⅰ 'S PROGRAM VER. DISPLAY MOTOR DRIVER PCB Ⅱ 'S PROGRAM VER. DISPLAY PAN&TILT DRIVER PCB'S PROGRAM VER. DISPLAY POWER PCB'S PROGRAM VER. TEST MENU DEBUG MODE (Default:OFF) EXIT DEBUG MODE AND RESET ACCESS DEBUG MODE SELFTEST MODE (Default:OFF) RESERVED SELFTEST MODE EXIT TESTMODE AND RESET SELFTEST MODE LAMP MENU ( Default : STAT ) DISPLAY STATE OF LAMP (END) 8/16 Pilot 1200 wash EN.doc...
-
Page 9: Dmx Control Channel Functions
DMX CONTROL CHANNEL FUNCTIONS The PILOT 1200 WASH uses 14 DMX channels. They are listed in the following table. ITEM CHANNEL DESCRIPTION Strobe 000010 Shuttering 011020 White 021034 Strobe 1 Strobe 2 035048 Strobe 3 049062 Strobe 4 063076 077090 Strobe 5 091104... - Page 10 000255 Tilt rotation in 16 Bit precision Control (when ext. channels disabled, 000048 Reserved this channel performed by channel 11) 049080 Reset 081112 Reserved 113144 Lamp off 10 seconds later 145223 Reserved 224255 Lamp on 10/16 Pilot 1200 wash EN.doc...
-
Page 11: Led Display
20 days and clean the internal optics at least once every 30 / 60 days. Do not use any organic solvent, e.g. alcohol, to clean the reflector mirror, dichroic colour filters or housing of the apparatus. Pilot 1200 wash EN.doc 11/16... -
Page 12: Troubleshooting
The lamp is at the end of specified type and rating. its life LIGHT OUTPUT 33° lux 3800 15° lux 22800 5700 2500 1420 DISTANCE 1.3m 2.6m 3.9m 5.2m 15° DIAMETER 2.96m 5.92m 8.88m 11.8m 33° DIAMETER 12/16 Pilot 1200 wash EN.doc... -
Page 13: Technical Data
PAN & TILT rotation in 16 Bit precision PAN & TILT Speed, adjustable Remote reset Lamp ON/OFF, remote or controlled by panel Display the using time of lamp and luminaire HOUSING: Metal and composite plastic (IP20) WEIGHT: 42Kg. SIZES: 13/16 Pilot 1200 wash EN.doc... -
Page 14: Electrical Diagram
ELECTRICAL DIAGRAM 14/16 Pilot 1200 wash EN.doc... -
Page 15: Component Order Codes
STROBE MOTOR 030040112 17HD001338L 5*15 IRIS MOTOR 030040112 17HD001338L 5*15 EFFECT WHEEL 030040112 17HD001338L 5*15 PAN&TILT DRIVE PCB 230020091 MOTOR DRIVER PCB I 230020120 MOTOR DRIVER PCB Ⅱ 230020121 DIGITAL PCB 230020122 POWER PCB 230020098 15/16 Pilot 1200 wash EN.doc... - Page 16 PR LIGHTING LTD. No. 571, Yingbin Road, Dashi, Panyu, Guangzhou, China PostCode: 511430 TEL: +86208478 1888 FAX: +86208478 6023 P/N: 321010231 Last Revision: 07: 05: 2006 16/16 Pilot 1200 wash EN.doc...
