PILOT 250
PR-2250
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep this
manual in a safe place for future reference.
PEARL RIVER LIGHT & ACOUSTICS INDUSTRIAL LTD.
Yingbin Road, Dashi Panyu, Guangzhou, 511430 China
h t t p : / / w w w . p r - l i g h t i n g . c o m
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pure Reliability PILOT 250
Summary of Contents for Pure Reliability PILOT 250
- Page 1 PILOT 250 PR-2250 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PEARL RIVER LIGHT & ACOUSTICS INDUSTRIAL LTD.
-
Page 2: Table Of Contents
DMX 512. It can be used as a stand-alone unit or linked to a controller, so it is suitable for many different applications. The PILOT 250 features 9 colours plus white on the colour wheel, 2 gobo wheels, one with 7 indexable, interchangeable rotating gobos, one with 7 interchangeable fixed gobos. DMX controlled focus, a 3 facet rotating prism and 3 beam angles. -
Page 3: Safe Usage Of The Projector
SAFE USAGE OF THE PROJECTOR When unpacking and before disposing of the carton check there is no transportation damage before using the projector. Should there be any transportation damage keep the carton, consult your dealer and do not use the apparatus. The projector is for indoor use only, IP20. -
Page 4: Installing The Projector
Always ensure that the structure to which you are attaching the projector is secure and is able to support a weight of 19Kg for each PILOT 250. For safety the projector should have a secondary fixing with a safety chain through the holes on the underside of the unit. -
Page 5: Power Supply – Mains
It is essential that each projector is correctly earthed and that electrical installation conforms to all relevant standards. Power consumption of the PILOT 250 is 410W at 220V. To change the voltage and/or frequency of the Pilot 250, see the details at the back of this manual. CONTROL CONNECTIONS... -
Page 6: Xlr Connectors
DMX TERMINATOR In Controller mode or Master/Slave mode, the DMX output has to be connected with a DMX terminator at the last fixture in the chain. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain. -
Page 7: Setup Options Table
SETUP OPTIONS TABLE GOBO WHEEL ROTATION (0-255) RESET HOT LAMP, FAIL TO START FIXED GOBO WHEEL (0-255) LAMP DAMAGED, FAIL TO START COLOUR WHEEL (0-255) ADDRESS SETTING DIMMER (0-255) LAMP ON/OFF CONTROLLER OPERATED SOFT RESET LAMP ON LAMP OFF RESET LAMP ON/OFF AND RESET FROM CONTROLLER FAN SPEED ADJUST HIGH SPEED... -
Page 8: Projector Dmx Start Address
PROJECTOR DMX START ADDRESS Each PILOT 250 must be given a DMX start address so that the correct projector responds to the correct control signals. This DMX start address is the DMX channel number from which the projector starts to “listen” to the digital control information being sent out from the controller. The PILOT 250 has 15 channels, so set the No. -
Page 9: Stand-Alone Mode
WHEEL 64-95 GOBO 2 96-127 GOBO 3 128-159 GOBO 4 160-191 GOBO 5 192-223 GOBO 6 224-255 GOBO 7 0-149 Step rotation in anti-clockwise direction (0-540°) 150-153 Stop (Position in 540°) 154-201 Rotate from slow to fast in clockwise direction GOBO ROTATION 202-207 Stop... -
Page 10: Changing The Gobos
CHANGING THE GOBOS ROTATING GOBO FIXED GOBO RETAINING SPRING SLIDE GOBO IN & OUT FROM SIDE OF WHEEL GOBO HOLDER FIXED GOBO WHEEL ROTATING GOBO WHEEL Unscrew the four (4) M4 bolts from the head cover, then carefully lift off the plastic cover Using a small screwdriver remove the rotating gobo retaining spring or push out the fixed gobo directly by hand. -
Page 11: Keeping The Projector Clean
KEEPING THE PROJECTOR CLEAN To ensure the reliability of the projector it should be kept clean. It is recommended that the fans should be cleaned every 15 days. The lens and dichroic colour filters should also be regularly cleaned to maintain an optimum light output. -
Page 12: Technical Data
TECHNICAL DATA VOLTAGES: 100/120/200/220/230/240V AC, 50Hz or 60Hz To Order. POWER CONSUMPTION: 410W @ 220V LAMP: Type : MSD 250W discharge lamp. Colour Temperature: 6700ºK Socket: GY9.5 (Single end) Manufacturers Rated Lamp Life: 2000 Hours COLOURS: 9 Dichroic colours plus white and variable speed Rainbow effect COLOUR TEMPERATURE CORRECTION: 2 Colour temperature correction filters GOBOS:... -
Page 13: Electrical Diagram
ELECTRICAL DIAGRAM ROTATING GOBO EFFECT COLOUR GOBO WHEEL WHEEL ROTATION FOCUS WHEEL MOTOR 8 MOTOR 9 MOTOR 10 MOTOR 11 MOTOR 12 COLOUR WHEEL SENS SENSOR ROTATING GOBO SENSOR EFFECTS D1 - D5 = DRIVER CHIPS P/N: 170050010 WHEEL SENSOR DRIVER PCB 1 MICROPROCESSOR +30V... -
Page 14: Component Order Codes
COMPONENT ORDER CODES NAME PART NO. REMARK TRANSFORMER 040030037 100V/120V/230V/60Hz THERMOSTAT 190010054 95℃/10A/250V CAPACITOR 140010018 60µF/370V BALLAST 040070053 230V/50-60Hz, 250W/3.6A IGNITOR 040090016 230V/50-60Hz, 4-5KV 300W LOWER FAN 030060001 DC12V/2.6W UPPER FAN 030060008 12V 0.43A LAMP 100050018 MSD 250 MOTOR 1 (TILT) 030040052 23HS0015L MOTOR 2 (PAN) - Page 15 To be carried out by qualified engineers only The power input settings of the Pilot 250 may be changed to suit the supply in the area that the unit is to be operated. The voltage and frequency is pre-set at the factory and will be marked on the exterior of the unit.
- Page 16 PEARL RIVER LIGHT & ACOUSTICS INDUSTRIAL LTD. Yingbin Road, Dashi, Panyu, Guangzhou, China Post-Code: 511430 TEL: 020-8478-1888 FAX: 020-8478-6023 P/N: 321010049 Last Revision: 10:06:2003 16/16 PILOT250manualEN.doc...
