THEATRE WASH
PR-3030
This product manual contains important information about the safe installation and
use of this projector. Please read and follow these instructions carefully and keep this
manual in a safe place for future reference.
PR LIGHTING LTD.
Yingbin Road, Dashi Panyu, Guangzhou, 511430 China
h t t p : / / w w w . p r- l i g h t i n g . c o m
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Pure Reliability PR-3030
Summary of Contents for Pure Reliability PR-3030
- Page 1 THEATRE WASH PR-3030 This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. PR LIGHTING LTD.
-
Page 2: Table Of Contents
This manual (1 PCS) INTRODUCTION Thank you for purchasing the product Theatre Wash, PR-3030. This product manual contains important information about the safe installation and use of this projector. Please read and follow these instructions carefully and keep this manual in a safe place for future reference. -
Page 3: Safe Usage Of The Projector
SAFE USAGE OF THE PROJECTOR The following points are important for safety as well as for the smooth installation and performance of the unit. When unpacking and before disposing of the package check there is no transportation damage before using the projector. Should there be any damage caused by transportation, consult your dealer and do not use the apparatus. -
Page 4: Installing The Projector
INSTALLING THE PROJECTOR This unit has been designed to be hung. Mount the bracket provided on the body of the projector, then suspend the projector via its bracket using a M12 size bolt and a nut. When you want to adjust the angle of the body of the projector, you only loosen the 2 locking knobs carefully and then adjust the angle of the body. -
Page 5: Power Connections
POWER CONNECTIONS The unit is supplied with a power cord. Should any other connections be required they must be carried out with the following configuration. Earth = Green/Yellow cord Neutral = Blue cord Neutral = Brown cord STAND-ALONE MODE Without connecting the controller, regulating the DIP switch as shown on the right, the apparatus will run in stand-alone mode. -
Page 6: Controller Mode - Dmx 512 Operation
DMX TERMINATOR In the Controller mode, the DMX output has to be connected with a DMX terminator at the last fixture in the chain. This prevents electrical noise from disturbing and corrupting the DMX control signals. The DMX terminator is simply an XLR connector with a 120Ω (ohm) resistor connected across pins 2 and 3, which is then plugged into the output socket on the last projector in the chain. -
Page 7: Keeping The Projector Clean
TABLE FOR SETTING THE DIP SWITCHES The following table lists the setting codes of the address of the DIP switches, and the luminaires are (For the from No.1 to No. 177. Each projector has 12 switches with the numbers from #1 to #12. Theatre Wash, set all #10 switches on the “... -
Page 8: Maintenance
MAINTENANCE If the lamp becomes damaged or deformed in any way it must be replaced. If the light from the lamp appears dim this would normally indicate that it is reaching the end of its life and it should be changed at once, old lamps run to the extremity of their life can explode. -
Page 9: Electrical Diagram
LIGHT OUTPUT ELECTRICAL DIAGRAM 9/10 Theatre wash.doc... - Page 10 COMPONENT ORDER CODES NAME PART NO. REMARK TRANSFORMER 040020025 230V AC 50Hz THERMOSTAT 190010035 120℃／15A250V 030060001 DC12V/2.6W 030060021 DC12V/2.8W LAMP 100010015 230V 1200W Halogen MOTOR 1 (FOR COLOUR– WHEEL 1) 030040024 17HS0002-03L, ? 5X28 MOTOR 2 (FOR COLOUR– WHEEL 2) SENSOR 171000008 MOC3022...
