Motor Unit Assembly Parts - Chamberlain Security+ HD200D Owner's Manual

Motor Unit Assembly Parts

6
7
KEY PART
NO. NO.
1 41A5615
2 41C4220A Gear and sprocket assembly.
3 41A2817
4 41B4245
5 41D181
6 4A1344
7 108D79
8 30B532
9 12A373
10 41A3150
11 41D3058
19
11
8
14
9
12
DESCRIPTION
Chain Spreader
Complete with: Spring washer,
thrust washer, retaining ring,
bearing plate, roll pins (2), drive
gear and worm gear, helical
gear w/retainer and grease
Drive/worm gear kit w/grease,
roll pins (2)
Line cord
End panels w/all labels
Light socket
Lens
Capacitor - 1/2 HP
Capacitor bracket
Terminal block w/screws
Universal replacement motor &
bracket assembly.
Complete with: Motor, worm,
bracket, bearing assembly, RPM
sensor
1
4
2
3
10
16
15
13
Drive
Gear
KEY PART
NO. NO.
12 41A5525-5
13 41A2818
14 41D3452
15 41A2822-1
16 41C4398A
17 41AC050-1
18 41C5497
41C5498
19 41A5484-1
41A2826
41A2825
38
18
17
5
(Down)
LIMIT SWITCH
Brown
Contact
Wire
DN
UP
Center Limit (Up)
Contact Contact
DESCRIPTION
Cover
Limit switch drive & retainer
Limit switch assembly
Interrupter cup assembly
RPM sensor assembly
Receiver logic board assembly.
Complete with: Logic board,
end panel w/all labels, light
socket
High voltage wire harness
Low voltage wire harness
End panel w/all labels
NOT SHOWN
Motor shaft bearing kit
Opener assembly hardware kit
(includes screws not
designated by a number in
illustration)
ASSEMBLY
Grey
Wire
Yellow
Wire
