REPAIR PARTS

Rail Assembly Parts

1

Installation Parts

1
5
8
13
12
4
6
4
2
3
6
7
10
11
9
2
3
KEY
PART
NO.
NO.
1
4A1008
2
41C5141-1
3
41A5665
4
144C56
5
41A5807
6
12D598-1
183A163
KEY PART
NO.
NO.
DESCRIPTION
1
41C494-2
Multi-Function door control panel
2
953CD
3-Button remote control
3
10A20
3V 2032 Lithium battery
4
29B137
Remote control visor clip
5
41A2828
Emergency release rope and handle
assembly
6
41B4494-1
2-Conductor bell wire, white and white/red
7
41A5047
Door bracket w clevis pin & fastener
8
41A5047-2
Header bracket w/clevis pin & fastener
9
41A5034
Safety reversing sensor kit (receiving and
sending eyes) with 3' (.9 m) 2-conductor
bell wire
10
178B34
Straight door arm section
11
12B776
Hanging brackets
12
178B35
Curved door arm section
13
41A5266-1
Safety reversing sensor brackets (2)
NOT SHOWN
41A5258-11
Installation hardware bag
(includes hardware listed on page 7)
114A3241
Owner's manual
37
5
DESCRIPTION
Master link kit
Complete trolley assembly
Complete rail
Idler pulley
Chain and cable
"U" bracket
NOT SHOWN
Wear pads
