Separate all hardware from the packages in the rail carton and the opener carton and group as shown below, for
the assembly and installation procedures.
Bolt
1/4-20x1-3/4" (8)
Lag Screw
5/16"-9x1-5/8" (2)
Lag Screw
5/16"-18x1-7/8" (2)
Carriage Bolt
5/16"-18x2-1/2" (2)
Clevis Pin
5/16"x2-3/4" (1)
Hardware
Assembly Hardware
1/4" - 20 x 5/8"
Hex Screw (4)
Installation Hardware
Carriage Bolt
1/4"-20x1/2" (2)
Hex Screw
5/16"-18x7/8" (4)
Handle
Screw
6ABx1-1/4" (2)
5
Lock Nut
1/4"-20 x 7/16 (12)
Sprocket Coupling Sleeve
Wing Nut (2)
Lock Washer 5/16" (6)
Ring Fastener (3)
Nut 5/16"-18 (6)
Dry Wall Anchors (2)
Screw 6-32x1" (2)
Clevis Pin
5/16"x1-1/4" (1)
Rope
Insulated
Staples (30)
Clevis Pin
5/16"x1" (1)
