Chamberlain 953EV-P2 Manual

For use with Chamberlain 315 MHz or 390 MHz garage door openers manufactured after
January 1, 1993. The garage door opener activates when the programmed button on the remote
control is pressed. The remote control can activate up to three garage door openers.
Make sure the garage door opener has a working light bulb because it is a programming indicator.
WARNING: This product can expose you to chemicals including lead, which are known to
the State of California to cause cancer or birth defects or other reproductive harm. For more
information go to www.P65Warnings.ca.gov
GARAGE ACCESS SYSTEM
REMOTE
MODELS 953EV, 953EV-P2,
953EVC AND 953EVC-P2
PREPARE
PROGRAM THE REMOTE CONTROL (953EV, 953EV-P2, 953EVC AND 953EVC-P2)
1
Press and hold the program button
the remote control until the LED on
the front of the remote control
turns on.
Press and release the Learn
button on the garage door
opener.
4
Learn
Button
The Learn LED will light.
Within 30 seconds...
GARAGE ACCESS SYSTEM
KEYCHAIN REMOTE
MODELS 956EV, 956EV-P2,
956EVC AND 956EVC-P2
LED
Learn
OR
LED
Green
or
Learn
LED
Red/Orange
Purple
2
Press and release the remote control button you wish to use the
number of times that corresponds with the garage door opener type:
# of Presses Garage Door Opener Type
1 Yellow Learn Button (Security+ 2.0
2 Purple Learn Button (315 MHz Security+
3 Red/Orange Learn Button (390 MHz Security+
4 Green Learn Button (390 MHz Billion Code)
5
Press the remote control button
programmed in step 2 until the
garage door opener lights flash
or two clicks are heard.
http://www.chamberlain.com/CatalogResourcesV3/en-us/shared/files/tucmanuals/114A5043SP.pdf
MODELS 953EV, 953EV-P2, 953EVC, 953EVC-P2,
956EV, 956EV-P2, 956EVC, AND 956EVC-P2
LED
Locate the Learn
button on the garage
door opener.
NOTE: Your garage door
opener may look different.
OR
Learn
LED
Yellow
® )
®
6
To test, press the programmed
button on the remote control...
3-BUTTON REMOTE CONTROLS
To prevent possible SERIOUS INJURY or
DEATH from a moving gate or garage door:
• ALWAYS keep remote controls out of
reach of children. NEVER permit children
to operate or play with remote controls.
• Activate gate or door ONLY when it can be
seen clearly, is properly adjusted and
there are no obstructions to door travel.
• ALWAYS keep gate or garage door in
sight until completely closed. NEVER
permit anyone to cross path of moving
gate or door.
Locate the Program button on the
remote control.
953EV, 953EV-P2,
953EVC AND
953EVC-P2
956EV,
956EV-P2,
956EVC AND
956EVC-P2
3
To exit programming mode,
press any remote control
button except the button
that was just programmed.
)
® )
7
Install the visor clip.
The garage door
opener will activate.
Para Manual en Español ir a:
Program Button
Program Button
