Suntec Wellness Klimatronic CoolBreeze 2500 TV Operating Instructions

CoolBreeze 2500 TV
OPERATING INSTRUCTIONS
PLEASE READ COMPLETELY BEFORE OPERATING

Fan Parts Identification

CAUTION
1. Do not plug the power cord into the wall outlet until the fan has been
completely assembled.
2. Use power source according to the electric specifications in the
rating label at the back of switch box.

HOW TO ASSEMBLE

The only tool required for the assembly is a screw driver.
MOUNTING OF THE FAN
Identification of the fan parts
1. Motor Housing
2. Rear Guard
3. Locking Nut
4. Blade
5. Blade Cap
6. Front Guard
7. Screw
Mounting the Rear Guard.
Mount the Rear Guard on to
the Motor Housing and secure it
with the Locking Nut.
Mounting the Blade.
Insert the Blade onto the
Motor shaft and tighten the
Blade with the Blade Cap.
Mounting the Front Guard
Hold the front guard to make sure
that the Trade Mark is level and
that the front guard are centered
over the rear guard. Then push all
the safety clips firmly into place.
CAUTION
Never operate the fan with a cracked or damaged blade.
1. Front guard
2. Blade
3. Blade knob
4. Blade screw
5. Rear guard
6. Motor housing
7. Oscillating control bar
