Related Manuals for Cola EMILY
Summary of Contents for Cola EMILY
- Page 1 Installation, use and maintenance manual Wood-burning stove model EMILY 48.41.10.021.GB – 07/09 Read the instructions carefully before installation and startup...
- Page 2 4.4 Cleaning the cast iron hotplate 4.5 Cladding maintenance 5 – ROUTINE STOVE CLEANING AND MAINTENANCE 5.1 The stove does not work 5.2 Difficult lighting 5.3 Smoke leaks 5.4 The glass gets dirty quickly 6– ENCLOSURES 6.1 Warranty certificate 6.2 "CE" marking information Emily...
-
Page 3: General Information
In case of operation anomalies, relight the stove only after eliminating the cause of the problem. The Manufacturer declines any liability for problems, breakage or accidents caused by failure to follow or apply the instructions contained in this manual. Emily... - Page 4 (depending on house insulation) kg/h Max. hourly wood consumption 1.82 Weight 115 kg Min. safety distance 200 mm (rear-right side-left side) mm (fig.1) 850 x 471 x 488 H x W x D) Dimensions ( Uscita fumi Fig.1 stove dimensions Emily...
-
Page 5: Accessories Supplied
UNI 10683/98: Standard prescribing the installation requirements for heat generators or appliances intended for cooking food, such as stoves and heating cookers with natural draught on fume side and forced draught with thermochemical power of <35kW burning natural wood. Emily... -
Page 6: Transport And Installation
For the end-user: Contact the service centre and/or your dealer to request replacement parts. For the dealer: To request any replacement parts contact the Cola s.r.l. service centre and/or send a fax clearly specifying the following: - stove model; - serial number;... -
Page 7: Room Ventilation
(α) slope slope Distance A Distance B 15° 1.00 m 15° 0.50 m 30° 1.30 m 30° 0.50 m Less than 1.85 m More than 1.85 m 45° 2.00 m 45° 0.50 m 60° 2.60 m 60° 0.50 m Emily... -
Page 8: Combustion Air Adjustment
(primary air control open 30%). The heat can then be increased a little at a time, so that the stove expands slowly and the paint and putty dry. Emily... - Page 9 4.2 Cleaning the glass The glass can be cleaned using a damp cloth and specific non-abrasive detergents. Do not clean the glass when the stove is operating. The glass must only be cleaned when the stove is cold. Emily...
-
Page 10: Troubleshooting
Make sure the primary air control is open. 5.4 The glass gets dirty quickly Make sure the fuel is of a recommend type. Make sure the wood is properly seasoned and dry. Too much fuel in the combustion chamber. Check the flue draught. Emily... -
Page 11: Warranty Certificate
The company reserves the right to make technical or aesthetic modifications to the products at any time without notice. The drawings, measurements, diagrams and any other configurations are given only by way of example. Emily... -
Page 12: Ce Marking Information
6.2 "CE" marking information CE MARKING INFORMATION Anselmo Cola EN 13240 : 2001 + A2 : 2004 Apparecchio domestico a combustibile solido Roomheater fired by solid fuels EMILY Ref. Distanza di sicurezza da materiali infiammabili 200 mm min Safety distance to adjacent combustible materials...
