Easy 3-Step Installation Guide
Before removing the adhesive protective liner, do a dry run and test each step
to make sure the installation will work. The SecureHold adhesive is meant to be
used once only and cannot be repositioned if done incorrectly.
Important:
Qdos wants to keep your children safe and for that we need you to do your part by
carefully reading and following the instructions below.
For installation videos and FAQs go to: QdosSafety.com
Parts List:
TV Mounting Bolts
6 mm
8 mm
TV
Mounting
Plate
Top Cam
Strap
Lock
5 mm
4 mm
Furniture
Hinge
Cam Lock
Pin
2-in-1 Anti-Tip
TV Straps
Furniture
Mounting Plate
Bottom
Cover for
Cam Lock
Wall Bracket
Wall Hardware
4x SecureHooks™
Wall
Bracket
6x 1.5"
(35 mm)
Optional
Screws
Advertisement
Related Manuals for Qdos 2-in-1 Anti-Tip TV Straps
Summary of Contents for Qdos 2-in-1 Anti-Tip TV Straps
- Page 1 Important: Qdos wants to keep your children safe and for that we need you to do your part by carefully reading and following the instructions below. For installation videos and FAQs go to: QdosSafety.com...
- Page 2 Step 1 - Attaching Straps to the TV Pull the furniture out from the wall. Release all the Cam Locks and extend the straps to the maximum length. Locate the upper VESA mounting holes on the back of the TV and select the correct bolt size to fit the holes. Attach both TV Mounting Plates.
- Page 3 2B - Screw into Stud Behind Drywall Locate the studs by using a stud finder. Carefully mark the center locations of each stud at the top of the furniture. Line up the straps as straight as possible from the TV with the closest stud.
- Page 4 Step 4 - Taking slack out of strap Slide Bottom Cam Lock buckles upwards toward the furni- ture Cam Locks to take some slack out of the straps. Final- ly, Push furniture back towards wall and pull upwards on the straps through the Furniture Cam Lock and lock both Furniture Cam Locks.
