- Page 1 SM 1050 SWITCHING POWER GENERATOR FOR 3 KW MAGNETRON SM 1050D: for main line 3 x 208V SM1050T: for main line 3 x 400V TECHNICAL NOTE...
- Page 2 SM 1050 Switch-mode power supplies for 3 kW magnetron Dichiarazione CE di Conformità CE Declaration of Conformity Nome del costruttore: ALTER s.r.l Manufacturer’s Name: Indirizzo del costruttore: Via Chiloni, 25 - 42100 Reggio Emilia - Italy Manufacturer’s Address: Dichiara che il prodotto:...
-
Page 3: Table Of Contents
- Dip-switch settings on power board ............page 13 - Components list ..................page 14 - Wiring diagram and specs for connectors #1,3,4 of SM1050D ..page 15 - Wiring diagram and specs for connectors #1,3,4 of SM1050T ..page 16 - Wiring diagram and specifications for connector #5 ...... -
Page 4: General Informations
SM 1050 Switch-mode power supplies for 3 kW magnetron General Informations This equipment satisfy the European Standard EN 61010-1 (=CEI 66-5) (=IEC 1010-1) approved by CENELEC on 9/3/1993. With reference to EN 61010-1 standard, note: this appliance must be installed and serviced only by qualified personnel. The appliance must only be used by persons acquainted with the regulations covering the application. -
Page 5: General Description
SM 1050 Switch-mode power supplies for 3 kW magnetron General Description Equipment ratings SM 1050D SM 1050T 3 x 208 3 x 400 Environmental conditions for all models File: SM1050_rz- June 1999 page 5 of 25... -
Page 6: Fuses
SM 1050 Switch-mode power supplies for 3 kW magnetron Fuses SM 1050D SM 1050T Auxiliary fuses Physical characteristics File: SM1050_rz - June 1999 page 6 of 25... -
Page 7: Equipment Installation
SM 1050 Switch-mode power supplies for 3 kW magnetron Equipment installation File: SM1050_rz- June 1999 page 7 of 25... -
Page 8: Handling Instructions
SM 1050 Switch-mode power supplies for 3 kW magnetron Handling instructions Wiring instructions SM1050T SM1050T high voltage output 5.3 kV File: SM1050_rz - June 1999 page 8 of 25... -
Page 9: Equipment Operation
SM 1050 Switch-mode power supplies for 3 kW magnetron Equipment operation Operating controls LED meaning: File: SM1050_rz- June 1999 page 9 of 25... -
Page 10: Alarm Information
SM 1050 Switch-mode power supplies for 3 kW magnetron Important note about alarms: any alarm condition, whether temporary or permanent, causes block of the equipment, which means no output power. Pls refer to next chapter "Alarms informations" for more explanations. Alarm information: File: SM1050_rz - June 1999 page 10 of 25... -
Page 11: Alarm Table
SM 1050 Switch-mode power supplies for 3 kW magnetron Alarm table $ODUP 7\SH &DXVHV 5HVHW Rack alarm Temporary Error between output vs ref. signal Auto (every second) Temporary Internal overtemperature Auto Permanent Anodic overcurrent Needed Tube overtemp. Temporary Magnetron overtemperature, or input connection Auto from magnetron thermoswitch open Arc detection... -
Page 12: Equipment Maintenance
SM 1050 Switch-mode power supplies for 3 kW magnetron Equipment maintenance Cleaning Fuses replacement Failure to comply with these instructions may involve considerable risks for the staff responsible for checking and using the equipment, as well as the risk of malfunctions of the equipment itself. -
Page 13: Layout Of Internal Components
SM 1050 Switch-mode power supplies for 3 kW magnetron Meaning of dip-switches on "master" board M136.x/100 VZLWFK )XQFWLRQ 1RWH Must be specified at Reference signal selection 0-10 V 0-5 V or 0-20 mA order Must be specified at Enable/Disable 0-20 mA signal Disable Enable order... -
Page 14: Components List
SM 1050 Switch-mode power supplies for 3 kW magnetron Components list (with reference to drawing at page 12) I I I I I I e t l e t l I I I I I I I I I I I I Note *: Position 2 is an alternative of position 3 File: SM1050_rz - June 1999 page 14 of 25... -
Page 15: Wiring Diagram And Specs For Connectors #1,3,4 Of Sm1050D
SM 1050 Switch-mode power supplies for 3 kW magnetron Only for model SM1050D (3x208Vac) File: SM1050_rz- June 1999 page 15 of 25... -
Page 16: Wiring Diagram And Specs For Connectors #1,3,4 Of Sm1050T
SM 1050 Switch-mode power supplies for 3 kW magnetron Only for model SM1050T (3x400Vac) File: SM1050_rz - June 1999 page 16 of 25... -
Page 17: Wiring Diagram And Specifications For Connector #5
SM 1050 Switch-mode power supplies for 3 kW magnetron Wiring diagram for connector #5 (common for both models SM1050D & SM1050T) (1st wiring example) (2nd wiring example) File: SM1050_rz- June 1999 page 17 of 25... -
Page 18: Wiring Diagram And Specifications For Connector #2
SM 1050 Switch-mode power supplies for 3 kW magnetron Wiring diagram for connector #2 (common for both models SM1050D & SM1050T) File: SM1050_rz - June 1999 page 18 of 25... -
Page 19: Block Diagram Of Sm1050 Unit
SM 1050 Switch-mode power supplies for 3 kW magnetron Block diagram of SM1050 power supply File: SM1050_rz- June 1999 page 19 of 25... -
Page 20: Accessories
SM 1050 Switch-mode power supplies for 3 kW magnetron Accessories filament transformer type FIL100S remotable microwave head type WG10253 File: SM1050_rz - June 1999 page 20 of 25... -
Page 21: Tm 030 Remotable Microwave Head (Closed Cabinet)
SM 1050 Switch-mode power supplies for 3 kW magnetron remotable microwave head type TM030 File: SM1050_rz- June 1999 page 21 of 25... - Page 22 SM 1050 Switch-mode power supplies for 3 kW magnetron TM030 microwave head File: SM1050_rz - June 1999 page 22 of 25...
-
Page 23: Wiring Example Sm1050 Vs Tm030 Remote Head
SM 1050 Switch-mode power supplies for 3 kW magnetron Wiring example of SM1050 with TM030 File: SM1050_rz- June 1999 page 23 of 25... -
Page 24: Wiring Example Sm1050 Vs Wg10253 Remote Head
SM 1050 Switch-mode power supplies for 3 kW magnetron Wiring example of SM1050 with WG10253 File: SM1050_rz - June 1999 page 24 of 25... -
Page 25: How To Order
FIL100S WG10253 TM030 44/1384050 44/1384402 Technical assistance For technical assistance as well as spare parts contact: ALTER srl via Chiloni, 25 42100 Reggio Emilia - ITALY Phone: +39 0522 553 820 Fax: +39 0522 553 577 File: SM1050_rz- June 1999...
