PM740T_r0 Correzione testo e dati Giugno 2003 PM740T_r1 Correzione cablaggio conn. 2 e 5 Settembre 2003 PM740T_r2 Aggiornamento dati fusibili e peso Settembre 2004 PM740T_r3 page 1 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
Warnings 2 general malfunctions of the equipment itself. Wiring instructions 6 Working modes 8 page 2 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
The intake air flow is approx. 150 m³/h. You must avoid mixing output air with inlet air. page 3 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
- install the cover and then power-on again. For instructions about fuse replacement please refer to related PM 740 PM 740 paragraph on the next page. page 5 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
- use a standard 19” wide enclosure with a depth of 800 mm (32”); - allow free intake of the cooling air from the front of the cabinet and exhaust air from back; page 6 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
9% of full value the unit generates power proportional to signal value: the signal is 0-10V. page 8 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
10 Volts on the analog input should be set to represent 100% of reverse power. Additional wiring and hardware is required to implement this function. page 9 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
MENU DIAGRAM Logo Alter Run Screen M ain M enu Host Unit Setup 1/2 Information 1/3 Pattern Setup Comunication Unit Setup 2/2 Information 2/3 Information 3/3 page 10 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
Page 12
Com Time Out. It is useful to set the maximum time gap *Not Present in this version between two comunication sessions, after this time the page 11 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
XI) Switch off the PM740 and wait 30 secs. XII) Switch ON the PM740: one of the first messages will be the new version number. page 12 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
Page 14
PM 740 T COMPONENT LAYOUT, bottom layer PM 740 PM 740 COMPONENT LAYOUT, top layer page 13 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
Power board M294 800000294 Power resistor RSZ10010R Note: Components marked with (*) are included on the con- nector set p/n 44SET1150 to be ordered separately page 14 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
Low Air Pressure Check head air filter. ALARM from head WATER FLOW Low Water Flow Check water flow is > 2l/min. ALARM in magnetron head page 19 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
Page 21
Check for restrictions in the air flow RACK detected in the b) Eliminate air recirculating between outlet on the OVERTEMP. rear and the front inlet rack page 20 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
No part of this publication may be reproduced without the express written consent of Alter. All rights reserved. page 21 of 21 File: PM740T_r3eng - Settembre 2004 - Manuale per: PM 740 T...
