OPERATOR and MAINTENANCE MANUAL
DELFI P.T.S. PORTABLE TOURNIQUET SYSTEM
P.T.S.
PORTABLE TOURNIQUET
SYSTEM
INFLATE
PRESSURE
TIME
DEFLATE
REF 9-2100-001
U.S. PATENTS 6,213,939; 5,931,853; 5,649,954; 4,469,099; PAT. PEND. and FOREIGN PATENTS
Delfi
medical
innovations inc.
Delfi Medical Innovations Inc.
Vancouver BC, Canada
800-933-3022 (US & Canada)
+ 604-742-0600 (Global)
Fax. + 604-742-3800
www.delfimedical.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the P.T.S. and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Delfi P.T.S.

Summary of Contents for Delfi P.T.S.

  • Page 1 OPERATOR and MAINTENANCE MANUAL DELFI P.T.S. PORTABLE TOURNIQUET SYSTEM P.T.S. PORTABLE TOURNIQUET SYSTEM INFLATE PRESSURE TIME DEFLATE REF 9-2100-001 U.S. PATENTS 6,213,939; 5,931,853; 5,649,954; 4,469,099; PAT. PEND. and FOREIGN PATENTS Delfi medical innovations inc. Delfi Medical Innovations Inc. Vancouver BC, Canada 800-933-3022 (US &...
  • Page 2 Delfi Medical Innovations Inc. (‘Delfi’) warrants the P.T.S. Portable Tourniquet System (‘product’) for one year from date of purchase. During the warranty period, Delfi will repair or replace, at its option, any product which is defective in materials or workmanship or which fails to meet the published specification for that model.

  • Page 3: Table Of Contents

    TABLE OF CONTENTS SECTION 1.0: DELFI PORTABLE TOURNIQUET SYSTEM (P.T.S.) GENERAL INFORMATION ..2 1.1 INTENDED USE ......................2 1.2 CONTRAINDICATIONS ....................2 1.3 PRECAUTIONS IN USE....................2 1.4 ADVERSE EFFECTS....................3 SECTION 2.0: P.T.S. INSTALLATION AND OPERATING INSTRUCTIONS .......... 4 2.1 SPECIFICATIONS ......................4 2.1.1...

  • Page 4: Delfi Portable Tourniquet System (P.t.s.) General Information

    INTENDED USE The Delfi Portable Tourniquet System (P.T.S.) is intended to be used by qualified medical professionals to temporarily occlude blood flow in a patient's extremity during surgical procedures on that extremity. Tourniquets are generally used for operations lasting less than 90 minutes. Tourniquets have been found...

  • Page 5: Adverse Effects

    • Prolonged tourniquet time can also produce changes in the coagulability of the blood with increased clotting time. Always minimize tourniquet time. • Tourniquet paralysis may result from excessive pressure. Insufficient pressure may result in passive congestion of the limb with possible irreversible functional loss. Always use the minimum effective tourniquet pressure, as described in the medical literature.

  • Page 6: Installation And Operating Instructions

    We recommend that this inspection be performed by a qualified biomedical engineer or other person thoroughly familiar with electronic medical devices. If the unit is damaged, notify the carrier and Delfi immediately. If the initial inspection results are satisfactory, a functional and calibration check should be performed after an 8-hour charge.

  • Page 7: Controls, Indicators, Displays, And Connectors

    CONTROLS, INDICATORS, DISPLAYS, AND CONNECTORS Refer to Figure 2.1 for the locations of the unit's controls, indicators, displays and connectors described below: ‘ON/STANDBY’ Button Turns the unit on or sets the unit to standby. In standby mode (powered off), the power to all instrument functions (i.e.
  • Page 8 An AC power supply adapter is supplied with every P.T.S. unit. It is a sealed unit designed specifically for the P.T.S. Contact Delfi if your power supply needs service or replacement. Plug the locking connector on the AC power supply cord into the AC power receptacle on the P.T.S. unit (see above), and plug the AC power cord into a power outlet (see below) whenever using the unit where AC power is easily accessible.

  • Page 9: Figure 2.1 P.t.s. Controls, Indicators, Displays, And Connectors

    Figure 2.1: P.T.S. Controls, Indicators, Displays, and Connectors P.T.S. PORTABLE TOURNIQUET SYSTEM INFLATE PRESSURE TIME DEFLATE...

  • Page 10: Figure 2.2 P.t.s. Pressure And Time Display Detail

    Figure 2.2: P.T.S. Pressure and Time Display Detail Figure 2.3: P.T.S. Message Display Detail...

  • Page 11: Initial Setup

    AC power supply may fail and may pose an electrical shock hazard. WARNING: Use battery packs supplied by Delfi only. Do not use any other batteries. Use of an improper battery pack may cause irregular operation that could be hazardous to the patient and/or user, and may permanently damage the P.T.S.

  • Page 12: Time Limit Set Point Adjustment

    c) Release the ‘PRESSURE + ‘ button. Within 2 seconds, the pressure display returns to “0”. d) Momentarily press the ‘PRESSURE – ‘ button and release (within 1 second). The pressure display reads "475*" (the new pressure set point) for 2 seconds. The pressure display then returns to “0”. e) Press and hold the ‘PRESSURE –...

  • Page 13: Pressure Low" And "Cuff Leak" Alarm Check

    2.5.6 “PRESSURE LOW” and “CUFF LEAK” ALARM CHECK: Connect the hose assembly and a cuff to the P.T.S. and press the ‘INFLATE’ button. The cuff inflates to the default pressure set point of 250 mmHg. Create a leak by partially detaching the hose from the unit while the cuff is inflated.
  • Page 14 memory during power up and are active until the user adjusts them (see Sections 2.5.3 and 2.5.4). These default values can be modified by the user (see Section 2.6). WARNING: In all cases it is essential to check the pressure and time limit set points and confirm that they are the desired values before inflating the cuff.

  • Page 15: Alarm Conditions

    ALARM CONDITIONS There are a number of conditions for which the P.T.S. will produce visual and audible alarms. Those conditions, indications and appropriate actions are shown in Table 2.1. The appropriate actions indicated are based on the most probable causes and should only be used as a guide. Other causes of alarm conditions may indicate a need for other actions.
  • Page 16 Message Action to silence Alarm Pressure Time Action required to correct Condition Description display alarm tone for 30 tone display display alarm condition (steady) seconds Tourniquet The unit’s elapsed TIME LIMIT Constant Normal Current Momentarily Press Press and hold ‘TIME + ’ to time timer, which advances tourniquet...
  • Page 17 Message Action to silence Alarm Pressure Time Action required to correct Condition Description display alarm tone for 30 tone display display alarm condition (steady) seconds Attempt to The unit has detected CUFF NOT Constant Current Normal Momentarily Press Press and hold ‘DEFLATE’ for 2 power off that the operator has DEFLATED...
  • Page 18 Message Action to silence Alarm Pressure Time Action required to correct Condition Description display alarm tone for 30 tone display display alarm condition (steady) seconds Leak in cuff The unit has detected a CUFF LEAK Constant Current Normal Momentarily Press Fix leak or hose large leak in a cuff...

  • Page 19: Alarm Silence Functions

    2.8.1 ALARM SILENCE FUNCTIONS Most audible alarm tones may be silenced for 30 seconds by momentarily depressing the ‘PRESSURE + ‘, ‘PRESSURE – ‘, ‘TIME + ‘, or ‘TIME – ‘ button. At the end of the silenced period, the alarm tone will restart if the alarm condition has not been corrected.

  • Page 20: Maintenance Instructions

    Delfi staff. Disassembly and attempted service by anyone other than Delfi staff poses a risk of electric shock, damage to the unit, and injury to the patient and will void all warranties. Internal parts in the P.T.S. can only be serviced at the factory by Delfi staff.

  • Page 21: Leak Testing

    Connect a leak-free Delfi Contour Lower Leg cuff, Contour Arm cuff, or a similar sized cuff to the P.T.S. using the hose assembly.

  • Page 22: Battery Testing And Replacement

    P.T.S. internal pneumatics. Repeat the test with a variety of different cuffs and hose assemblies. If the unit continues to fail, the leak is internal and the P.T.S. unit must be serviced by Delfi. 3.5 BATTERY TESTING and REPLACEMENT CAUTION: Risk of electric shock.

  • Page 23: Troubleshooting Guide

    ERROR” alarm below). Battery pack Remove battery cover and ensure battery pack is disconnected. securely plugged in. Unit does not turn on Internal hardware Contact Delfi. (with AC power failure. Defective AC connected). adapter/cord assembly. Cuff does not inflate. Internal hardware Contact Delfi.
  • Page 24 Deflate cuff and ensure it deflates fully (cannot be set to (disconnect hose if required) to clear “CUFF NOT standby) DEFLATED” alarm. Internal hardware Contact Delfi. Unit can be powered off by failure unplugging the AC power and removing the battery pack (see Section 3.5).

  • Page 25: Internal Hardware Servicing

    Delfi staff. Disassembly and attempted service by anyone other than Delfi staff poses a risk of electric shock, damage to the unit, and injury to the patient and will void all warranties. Internal parts in the P.T.S. can only be serviced at the factory by Delfi staff.
  • Page 26 Delfi Medical Innovations Inc. Vancouver BC, Canada 800-933-3022 (US & Canada) + 604-742-0600 (Global) Fax. + 604-742-3800 www.delfimedical.com © 2003 Delfi Medical Innovations Inc. Abatis Medical Technologies Limited Printed in Canada Ballybrohan, Killaloe 4-2100-024 Rev. 3 County Claire, Ireland (Eire)
