- Page 1 ZVK-007 Keyboard USERS MANUAL SECURITY with VISION...
-
Page 2: Table Of Contents
MEYERTECH LIMITED ISSUE 09 CONTENTS Installation EQUIPMENT CONNECTING THE ZVK-007 TO THE ZoneVu NETWORK KEYBOARD ADDRESS SERIAL COMMUNICATIONS GETTING STARTED POWER-UP MESSAGES LOGGING ON MODE SELECTION CLASIK MODE CLASIK MODE FACILITIES SELECTING A CAMERA SELECTING A MONITOR CAMERA CONTROL RELEASING CAMERA CONTROL... - Page 3 MEYERTECH LIMITED ISSUE 09 SELECTING A TRUNK SELECTING A CAMERA SELECTING A MONITOR PCI MODE PCI MODE FACILITIES SUPERVISOR LEVEL SUPERVISOR LEVEL FEATURES SELECTING AN OPTION PASSWORDS 6.3.1 HANGING A ASSWORD MODE ACCESS KEYBOARD SET-UP 6.5.1 EYBOARD AMERA CCESS 6.5.2 EYBOARD ONITOR CCESS...
- Page 4 MEYERTECH LIMITED ISSUE 09 Whilst every effort has been made to confirm the information in this document is correct, MEYERTECH LIMITED cannot accept any liability for any errors, omissions and or incorrect information contained within this document. No part of this document may be reproduced or distributed in any form or by any means without prior written consent from MEYERTECH LIMITED MEYERTECH LIMITED are committed to continuous product development and therefore reserve the right to change specifications without notice.
-
Page 5: Installation
Each keyboard connected to the ZoneVu network requires a unique Module Access Code (MAC) to function correctly. Set the MAC by following the procedure in Section 6.5.3. NOTE ! The MIC (Module Identification Code) is not used by the ZVK-007 and can be ignored. 1.4 SERIAL COMMUNICATIONS... -
Page 6: Getting Started
Matrix Mode 2.2 LOGGING ON The ZVK-007 has four levels of access, three User levels and one Supervisor level and is fully LOG ON / LOG OFF Password Protected. USER LEVELS can be programmed to allow access to different modes e.g. - CLASIK and PCI. -
Page 7: Mode Selection
MEYERTECH LIMITED ISSUE 09 2.3 MODE SELECTION Once Logged On the display will show SELECT MODE LOG OFF STEP 1 Press the MODE key to cycle through the Modes available for this USER LEVEL. LOG OFF INFO In sequence the display will show for example CLASIK MODE VCR MODE STEP 2... -
Page 8: Selecting A Camera
MEYERTECH LIMITED ISSUE 09 3.2 SELECTING A CAMERA STEP 1 Using the Numeric Keypad enter the digits of the Camera Number to be selected. INFO Each Digit entered will be displayed adjacent to CAMERA. STEP2 Press the ENT Key. INFO The display will then either retain the camera entered indicating a valid entry or show CAMERA - ERROR or CAMERA - DENIED To select another Camera repeat process from Step 1. -
Page 9: Releasing Camera Control
MEYERTECH LIMITED ISSUE 09 3.5 RELEASING CAMERA CONTROL The PTZ key when pressed will release control of the Camera, (so other keyboards can access it) without having to select another Camera. The second function of the PTZ key is to take control of a Camera without having to use the JOYSTICKS etc. -
Page 10: Global Facility
MEYERTECH LIMITED ISSUE 09 3.8 GLOBAL FACILITY The GLOBAL facility allows a number of camera functions to be activated on all cameras in the system with a single keystroke. The global facility can be used with the following camera control facilities. -
Page 11: Latched Camera Functions
MEYERTECH LIMITED ISSUE 09 3.11 LATCHED CAMERA FUNCTIONS Camera control keys are provided for the following camera latched functions WIPE LAMP AUX1 IRIS AUTO-MANUAL STEP 1 Press the function key you require or select camera control by first pressing the PTZ key and then select the latched function you require. -
Page 12: Electing Ones
MEYERTECH LIMITED ISSUE 09 3.12.1 S ELECTING ONES Zones are selected via the dedicated Zone Keys Z1M - Z8M. e.g. pressing Z4M would select Zone 4. Confirmation of which Zone has been selected will be displayed on the LCD for approximately two seconds. -
Page 13: Selecting A Trunk
MEYERTECH LIMITED ISSUE 09 INFO A Trunk will then be automatically selected and displayed on the current monitor. The display next to the site number will update to show the status of the selected trunk as follows: C – Control, operator has control of the trunk D –... -
Page 14: Selecting A Monitor
MEYERTECH LIMITED ISSUE 09 4.5 SELECTING A MONITOR As in classic mode. The site number and trunk status is updated as well as the camera number. 5. PCI MODE 5.1 PCI MODE FACILITIES CAMERA CONTROL PAN & TILT ZOOM FOCUS IRIS IRIS AUTO/MANUAL - AUX1 - AUX2 - LAMP - PWI - WASH - WIPE PCI MODE (PC Interactive Mode) allows the Keyboard to function interactively with a PC. -
Page 15: Selecting An Option
MEYERTECH LIMITED ISSUE 09 ESC TO LOG OFF ZVR CONFIG PASSWORDS ZVM CONFIG MODE ACCESS CAMERA CONFIG KEYBOARD SET-UP FEATURE ACCESS 6.2 SELECTING AN OPTION STEP 1 Press the MODE key until the option is displayed STEP 2 Press the ENT key 6.3 PASSWORDS SUPERVISOR PASSWORDS... -
Page 16: Mode Access
The display may also show that the MODE will be available as a future software release by showing SUPERVISOR MODE ACCESS USER LEVEL 1 LEVEL ZONEVU FUTURE FEATURE STEP 4 To change the access status for a particular category press the PROG key the display will show SUPERVISOR... -
Page 17: Eyboard Amera Ccess
MEYERTECH LIMITED ISSUE 09 STEP 1 Press the MODE key until the required option is displayed. With each press the display will show - ESC TO LOG OFF MONITORS ENGINEERING CAMERAS ZONAL SWITCHING STEP 2 Press the ENT key 6.5.1 K EYBOARD AMERA CCESS... -
Page 18: Eyboard Ngineering Acilities
INFO If the number is less than 10 the leading zero MUST be entered. INFO Not all ZoneVu controllers support 16 keyboards. Therefore the MAC must be set accordingly. KBD PRIORITY Enter a number in the range 1 to 9.9 being the highest priority. -
Page 19: Feature Access
MEYERTECH LIMITED ISSUE 09 STEP 5 To enter a Monitor Press the MON key and use the numeric keypad to enter a number in the range 1 - 64 followed by the ENT key. STEP 6 To enter a Camera use the numeric keypad to enter a number in the range 0 - 512 followed by the ENT key. -
Page 20: Zvr Configuration
MEYERTECH LIMITED ISSUE 09 6.7 ZVR CONFIGURATION ZVR CONFIG allows camera receivers to be configured from the comfort of the keyboard by utilising the camera receiver OSD (On Screen Display) The display will show SUPERVISOR CONFIGURATION LEVEL ZVR CONFIG STEP 1 Press the ENT key the display will show SUPERVISOR 510 CONFIG... -
Page 21: Camera Configuration
MEYERTECH LIMITED ISSUE 09 Selecting a menu displays different options, selecting an option allows it to be changed. Options which require text or numeric input, will clear ready for input when selected. Otherwise the option toggles through the choices each time it is selected. Text and numbers can be entered directly from the keypad. -
Page 22: Zvm-Configuration
MEYERTECH LIMITED ISSUE 09 6.9 ZVM-CONFIGURATION ZVM CONFIG allows the supervisor to configure the video matrix features e.g. camera captions, time & date etc. from the keyboard by using the video matrix OSD facilities. The display will show SUPERVISOR CONFIGURATION LEVEL ZVM CONFIG STEP 1... -
Page 23: Vcr Mode
MEYERTECH LIMITED ISSUE 09 7. VCR MODE The ZVK-007 can remotely control up to eight VCR’s by serial links and a MEYERTECH Protocol Gateway. VCR facilities provided are - PLAY FORWARD SEARCH RECORD REVERSE SEARCH STOP FRAME ADVANCE PAUSE FRAME REVERSE ADVANCE... -
Page 24: Mux Mode
MEYERTECH LIMITED ISSUE 09 8. MUX MODE The ZVK-007 can remotely control up to sixteen Multiplexers by serial links and a MEYERTECH Protocol Gateway. MUX facilities provided are - FULL SCREEN ACTIVITY MULTI SCREEN HOLD PICTURE IN PICTURE ENCODE DECODE LIVE 8.1 SELECTING A MULTIPLEXER... -
Page 25: Trouble Shooting Guide
ISSUE 09 9. TROUBLE SHOOTING GUIDE This Trouble Shooting Guide should be used in the first instance of encountering any problems with the ZVK-007. If problems persist, contact MEYERTECH on the Technical Help line numbers given on page 30. Symptom... -
Page 26: Declaration Of Conformity
Manufacture’s Address: MEYERTECH Limited Office Block One Southlink Business Park Oldham OL4 1DE Declares, that the product(s): Product Name : ZVK-007 Keyboard Model(s): Product Options: Conforms to the following Product Specifications: EN55022 CLASS B EN50093 EN60950 Amendments 1, 2, & 3 1992... -
Page 27: Product Warranty
MEYERTECH LIMITED ISSUE 09 11. Product Warranty MEYERTECH LIMITED warrants that at the time of shipment the products manufactured by Meyertech will be free from defects in material and workmanship. Should any defects appear within twelve months from date of shipment, Meyertech Limited shall at it’s sole discretion repair or replace the defective material. -
Page 28: Document History
MEYERTECH LIMITED ISSUE 09 12. DOCUMENT HISTORY ZVK-007 Keyboard Users Manual : MAN-007 ISSUE DATE CHANGE RECORD 7 October 1997 First Issue in new format 18 July 2001 Re-issued for Meyertech Limited 20 June 2002 Addition of ZVR-530 config and Site mode... - Page 29 MEYERTECH LIMITED ISSUE 09 NOTES MAN-007 http://www.meyertech.co.uk Page 29...
- Page 30 MEYERTECH LIMITED ISSUE 09 MEYERTECH LIMITED SECURITY with VISION Office Block One Southlink Business Park Oldham England OL4 1DE Sales Support Technical Support +44 (0)161 628 8406 +44 (0)1724 278 833 +44 (0)161 628 9811 Email: technical@meyertech.co.uk Email: sales@meyertech.co.uk http://www.meyertech.co.uk Page 30 http://www.meyertech.co.uk MAN-007...
