- Page 1 GAZEBO H E X A G O N A L E V E N T T E N T YEAR A S S E M B L Y G U I D E...
- Page 2 Sun Smart steps: slip on clothing, slop on sunscreen, slap on a hat, slide on sunglasses and seek shade. To register your product, go to coolaroo.com. The product code can be found printed above the barcode on the product packaging, alternatively you can find it on the relevant coolaroo.com product page.
- Page 3 4.5m 3.05m HEXAGONAL EVENT TENT A S S E M B L Y G U I D E STEP 1 Working with a partner on the opposite side, stand frame upright and grasp the two outer legs. Slightly lift the frame off the ground and each take a step backwards.
- Page 4 STEP 4 Secure the fabric top to the frame by wrapping the straps around the roof tubes and cross beams. Pull down the inside valances to cover the beam tubes. Fasten the hook and loop straps to the adjacent valances. STEP 5 Lift two adjacent outer legs and gently pull down inner legs until the buttons pop into position.
- Page 5 D I S A S S E M B L Y STEP 1 With a partner, lift two adjacent outer legs slightly, press the Push Button 1 button on each leg and push the inner leg section up into the outer leg. Repeat this for all legs. Undo the fabric straps from the roof tubes and cross beams.
- Page 7 The best under the sun Coolaroo is the leader in shade fabric technology. Our extensive range of attractive shade solutions is carefully manufactured to protect your home, garden and family from the harsh sun. coolaroo.com WARNING When assembling and using this product, safety precautions should always be followed to reduce the risk of personal injury and damage to equipment.
