- Page 1 GAZEBO P A G O D A YEAR A S S E M B L Y G U I D E...
- Page 2 Sun Smart steps: slip on clothing, slop on sunscreen, slap on a hat, slide on sunglasses and seek shade. To register your product, go to coolaroo.com. The product code can be found printed above the barcode on the product packaging, alternatively you can find it on the relevant coolaroo.com product page.
- Page 3 3.6m 2.93m PAGODA A S S E M B L Y G U I D E STEP 1 Working with a partner on the opposite side, stand frame upright and grasp the two outer legs. Slightly lift the frame off the ground and each take a step backwards.
- Page 4 STEP 4 Engage the slider at each corner by pushing it up while holding down the top of the leg until it locks into place. STEP 5 Secure the canopy fabric to the frame by wrapping the straps around the roof tubes and cross beams. STEP 6 Lift two adjacent legs from the top outer section and pull down inner leg sections until they lock into position.
- Page 5 D I S A S S E M B L Y STEP 1 Release push button on each leg and shorten the frame to its original height. Undo the fabric straps from the roof tubes and cross beams. STEP 2 Release sliders on all four corners, depressing the push button and gently pushing each corner down.
- Page 7 The best under the sun Coolaroo is the leader in shade fabric technology. Our extensive range of attractive shade solutions is carefully manufactured to protect your home, garden and family from the harsh sun. coolaroo.com WARNING When assembling and using this product, safety precautions should always be followed to reduce the risk of personal injury and damage to equipment.
