- Page 1 MODEL BL090Y19019 VM Innovations Assembly Instructions 877-472-4296 www.vminnovations.com...
- Page 2 Consumer Service Department. Please be aware of your product’s Limited Warranty for the return/refund policy from the store, We, at Lancaster, cannot handle the product which is out of product’s limited warranty since we only provide available parts. Thank you!
-
Page 3: Tools Required
English TOOLS REQUIRED Phillips Screwdriver - Not Included Standard (Flat Head Screwdriver) - Not Included Wrench - Included Power Tools: Set to Low Torque RECOMMENDED Electric Screwdrivers may be helpful during assembly; however, please set a low torque and use extreme caution. High Torque Over Tightened IMPORTANT NOTICE! This product is intended for INDOOR use only. -
Page 4: Parts Identifier
English PARTS IDENTIFIER PART NUMBER FOR FIG. 8 FIG NUMBER PART QUANTITY PART NAME Mainframe FOR FIG. 7 FOR FIG. 7 FOR FIG. 2 FOR FIG. 1 Lower Side Apron Lower End Apron Leg Panel Support Leg Top Panel - A FOR FIG. - Page 5 English ACCESSORIES FOR FIG. 16 FOR FIG. 16 Chalk Triangle Brush FOR FIG. 16 Billiard Ball Set HARDWARE FOR FIG. 2 FOR FIG. 2, 9 FOR FIG. 2 FOR FIG. 6. 7 M8x41mm Bolt M8 Spring Lock Washer M8 Washer 4x15mm Screw FOR FIG.
-
Page 6: Before Assembly
English PRE-INSTALLED PARTS FOR FIG. 11 FOR FIG. 11 FOR FIG. 7 FOR FIG. 7 Corner Pocket Side Pocket M6 “T” - Nut M8x10mm Nut FOR FIG. 2, 9 FOR FIG. 1 FOR FIG. 2 Square Nut with Screws M8 “T” - Nut M8x20mm Nut BEFORE ASSEMBLY Find a clean, level place to begin the assembly of your product. - Page 7 English ASSEMBLY FIG. 1 Pre-installed FIG. 2 Pre-installed Pre-installed Note: Do NOT tighten the Bolts (A11) until FIG. 9. (Continued on the next page.) www.vminnovations.com...
- Page 8 English ASSEMBLY FIG. 3 Note: For plastic legs - A, B (7 & 8), please follow the illustration and the picture accordingly, lock them together in the order of 1, 2, 3, 4, 5, 6, 7. Note: You will hear a “click” sound when the legs have successfully locked together.
- Page 9 English ASSEMBLY FIG. 4 Note: For plastic legs - E, D (11 & 10), please follow the illustration and the picture accordingly, lock them together in the order of 1, 2, 3, 4. IMPORTANT: You will hear a “CLICK” sound when snapping the Legs together.
- Page 10 English ASSEMBLY FIG. 5 FIG. 4 Assembly Note: For plastic legs - C (9), please follow the illustration and the picture accordingly, lock them together in the order of 1, 2, 3, 4. IMPORTANT: You will hear a “CLICK” sound when snapping the Legs together. This will indicate that the Legs are locked firmly in place.
- Page 11 English ASSEMBLY FIG. 6 FIG. 2 Assembly FIG. 3 Assembly FIG. 5 Assembly (Continued on the next page.) www.vminnovations.com...
- Page 12 English ASSEMBLY FIG. 7 TOP VIEW: Part 12 Pre-installed Pre-installed SIDE VIEW: Part 12 Note: Arrow on the backside of Apron Corners shows direction to Note: Flush with Aprons slide the Apron Corners down. (Continued on the next page.) www.vminnovations.com...
- Page 13 English ASSEMBLY FIG. 8 Note: Make sure “FLAPS” on Top Leg Panels are FLUSH AGAINST APRONS before inserting Screws. (Continued on the next page.) www.vminnovations.com...
- Page 14 English ASSEMBLY FIG. 9 FIG. 6 Assembly Pre-installed Note: After this step, tighten the Bolts (A11) (See FIG. 2). (Continued on the next page.) www.vminnovations.com...
- Page 15 English ASSEMBLY FIG. 10 Note: Avoid sideways pressure on Legs when turning over. Note: Go back and make sure that all connections are tightened. DO NOT LEAN THE HOLD BY THE CABINET DO NOT HOLD THE TABLE TABLE ON ITS LEGS TABLETOP BY THE LEGS CAUTION...
- Page 16 English ASSEMBLY FIG. 11 NOTE: DO NOT lift the table by the pockets. If you move the table, do not lift it by placing your hands beneath the pockets and do not lean or put pressure on them. Do not lean or sit on the end or side rails as this may damage the table. (Continued on the next page.) www.vminnovations.com...
- Page 17 English ASSEMBLY ASSEMBLE THE CUE RACK FIG. 12 FIG. 13 (Continued on the next page.) www.vminnovations.com...
- Page 18 English ASSEMBLY ASSEMBLE THE CUE RACK FIG. 14 FIG. 15 (Continued on the next page.) www.vminnovations.com...
- Page 19 English ASSEMBLY ASSEMBLE THE CUE RACK FIG. 16 BL090Y19019 (The last page.) www.vminnovations.com...
- Page 20 www.vminnovations.com...
