Canon PIXMA iP5200R Setup Manual page 25

7
Setup automatically detects the printer.
The iP5200R connected with a USB cable is detected
automatically.
When the printer is detected automatically
The printer is detected automatically if no operation is
required for connecting to the printer. Setup proceeds to
step 8.
If the Set Printer IP Address dialog box is displayed
If the printer is not detected automatically, the Set
Printer IP Address dialog box is displayed. Click
Connect to connect to the printer. If the printer is still
not detected, see "The Set Printer IP Address / Printer
IP Address Setup dialog box is displayed during
setup" in "Troubleshooting" on page 58.
8
When the screen shown on the left
appears, remove the USB cable, and
click Next.
To change the port name, click Set Port Name. For
details, see "Changing the port name" in
"Troubleshooting" on page 61.
9
Place the printer in the location where
you will use it, then turn it on.
10
Click Next in the Connection
Performance Measurement dialog
box.
Measuring of the communication status starts, and the
results are displayed.
Measuring takes a few minutes. You can cancel
measuring by clicking Cancel.
You also examine the detailed status of the
communication link after setup by using the Canon IJ
Network Tool.
23
