NICHARGE
UNIFIX 50
EN
Le support universel
(sol, mur, mât, ...)
16/04/2018
www.uniteck.fr
CO00117

Advertisement

loading
Need help?

Need help?

Do you have a question about the UNIFIX 50 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Uniteck UNIFIX 50

  • Page 1 NICHARGE UNIFIX 50 Le support universel (sol, mur, mât, …) 16/04/2018 www.uniteck.fr CO00117...
  • Page 2 UNIFIX 50 Dear customer, we thank you for purchasing one of our Uniteck products. Please read carefully all instructions before using your product. Unifix brackets have been specially designed to fix your Unisun photovoltaic panels or equivalent (see part compatible panels): •...
  • Page 3: Safety Instructions

    UNIFIX 50 PANEL COMPATABILITY With the design based on the use of Oblong drilling, Unifix allows the fixing of different panels of the market. Unifix accepts 1 panel, with the spacings and dimensions of panels indicated below. L (p) L (e)
  • Page 4 UNIFIX 50 RECOMMENDATIONS Mount Unifix brackets only on surfaces with sufficient lift. Consider the additional load with panel: Support Panel Unifix 50 = 2,6 kg Unisun 50.12M / 55.12 BC =4,1 kg / 3,8 kg Fastening: to prevent large quantities of snow from accumulating behind the sensor, install appropriate shut-off gates upstream.
  • Page 5 UNIFIX 50 - PREPARATION Easy to install, Unifix 50 can be fixed either: • on a rigid horizontal or vertical surface (eg wall, concrete floor, wood frame). • on round mast with a diameter of 40 to 60 mm (supplied flange)
  • Page 6 UNIFIX 50 - PREPARATION BEFORE MOUNTING • Assemble the brackets n° 7 on your Unisun photovoltaic panel M8x20 • Attach parts n°1 and n°2 to part n°4 according to the size of your solar panel. • Pre-tighten the nuts. The final tightening will be carried out at the end of the assembly.
  • Page 7 UNIFIX 50 - WALL MOUNTING / FLOOR / ROOF • Attach your bracket with 8 screws that fit your surface (screws and plugs not included). 470 mm www.uniteck.fr 15/25...
  • Page 8 UNIFIX 50 - WALL MOUNTING / FLOOR / ROOF • Unifix has a multi-position tilt system. (10 positions). Set the desired tilt to the desired orientation. Electrical performance depending on tilt and panel 0° orientation 30° 60° 90° Adjustable 0°...
  • Page 9 UNIFIX 50 FIXING ON ROUND MAT (40 TO 60 MM DIAMETER) • Attach the bracket to the mast with its flange and its associated screws. M8x100 n°13 • Unifix has a multi-position tilt system. (10 positions). Set the desired tilt to the desired orientation 0°...
