Termostat inteligent PNI CT36
fara fir cu WiFi, control prin Internet pentru centrale
Wireless smart thermostat PNI CT36
Internet controlled for central heating
Manual de utilizare / User manual
RO
Manual de utilizare.....................................
EN
User manual...............................................
termice
2
8
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for PNI CT36
Summary of Contents for PNI CT36
- Page 1 Termostat inteligent PNI CT36 fara fir cu WiFi, control prin Internet pentru centrale termice Wireless smart thermostat PNI CT36 Internet controlled for central heating Manual de utilizare / User manual Manual de utilizare........User manual..........
-
Page 2: Informatii Generale
INFORMATII GENERALE Termostatul inteligent PNI CT36 a fost dezvoltat pentru a oferi clientilor un plus de confort zi de zi in spatiile de locuit, la birou sau in alte incinte oferind posibilitatea de a monitoriza si porni / opri sistemele... - Page 3 DETALII TEHNICE / SPECIFICATII - Alimentare unitate centrala: 2 baterii AAA - Alimentare unitate receptor: 230VAC 50/60Hz - Tip comanda unitate receptor : releu NO/NC (normal deschis/) fara potential ( neenergizat) - Parametri de functionare releu: maxim 250 V, maxim 10 Amperi (rezistiv), Curent AC/DC - Compatibil cu toate centralele termice prevazute cu intrare termostat compatibil cu releu NO fara potential.
- Page 4 INSTRUCTIUNI SI ATENTIONARI LA PRIMA UTILIZARE: 1. Sistemul vine cu unitatile termostat si receptor imperecheate din fabrica. La instalare mai este necesara doar legarea / imperecherea unitatii receptor cu Router-ul Wireless din apropiere. 2. La prima punere in functiune termostatul / Unitatea receptor semnaleaza luminos prin LED = “clipeste rar”...
- Page 5 primite catre/de la la aplicatia de mobil iar pictograma lipseste de pe ecran . 1. Apasati lung butonul de imperechere cod de pe receptor pana cand LED-ul 1 clipeste rapid. 2. Cu ecranul inchis ( apasati butonul On/Off) apasati lung butonul M de pe unitatea centrala pana apare pe ecran un cod din 4 cifre.
- Page 6 CONFIGURARE PROGRAME ZILNICE Aceasta configurare poate fi facuta si din aplicatia de smartphone, procedura pe care o recomandam. De pe unitatea termostat cu ecranul aprins apasati lung butonul P ( 6-7 secunde) pentru a intra in setarile de PROGRAM. Zilele saptamanii sunt fixate de Luni pana Duminica (1 ~ 7), fiecare zi are 4 perioade de timp (1 ~ 4).
- Page 7 250 V AC / DC. Regasiti exemple de conectare cu anumite modele de centrale termice la sfarsitul manualului. EXEMPLE DE CONECTARE CU CENTRALE TERMICE - THERMOSTAT PNI CT36* *Instalarea trebuie facuta obligatoriu doar de catre instalator autorizat si doar dupa consultarea manualelor, si verificarea conexiunilor si compatibilitatea acestora.
- Page 8 3. Vaillant Ecotec Pure 4. Motan Max Optimus INSTALARE FIZICA SI DIMENSIUNI Unitatea termostat poate fi montata in 2 moduri: 1. Pe masa sau pe o zona plana cu suportul alb prezent in colet: 2. Pe perete cu suportul de perete inclus:...
-
Page 9: General Informations
(WiFi router) close to where thermostat is installed. GENERAL INFORMATIONS The PNI CT36 smart thermostat has been developed to provide customers extra day-to-day comfort in their homes, in the office or other premises, offering the ability to monitor and turn on or off heating systems either automatically scheduled for every day of week, either remotely, anytime and anywhere via the Internet with dedicated app for Android or iOS Smartphone. -
Page 10: Main Unit Description
TECHNICAL DETAILS / SPECIFICATIONS - Main unit power supply: 2 AAA batteries - Receiver power supply: 230VAC 50 / 60Hz - Receiver unit command type: NO Relay (normally open) 10 Amps max not energized / dry contact - Relay parameters: 250 V max, 10 Amps max (rezistiv), AC/DC curent - Set point range temperature: 5 - 35 C ( 0.5 C step) - Page 11 FIRST USE WARNINGS AND INSTRUCTIONS 1. The system comes with main unit and receiver paired from factory. Before use, you only need to pair the receiver unit with the nearby Wireless Router. 2. At first start, the thermostat / receiver unit signals by LED 1 = “ slow blinks” that means it is necessary to connect unit to the wireless router with Internet access.
- Page 12 received to / from the mobile application and the icon is missing from screen. 1. Press and hold the code pairing button on the receiver until LED 1 flashes quickly. 2. With the screen closed (press the On / Off button), press and hold the M button on the center unit until a 4-digit code appears on the screen.
-
Page 13: Advanced Parameter Settings
SET UP DAILY PROGRAMS This setup n can also be done from smartphone app, wich we recommend. With the on-screen display, press and hold the P button (6-7 seconds) to enter the PROGRAM settings. Days of the week are fixed from Monday to Sunday (1 ~ 7), each day has 4 time periods (1 ~ 4). Each press of the P button can be performed in the next setting. - Page 14 250 V AC / DC . Find examples of connections with certain models of Gas boiler Systems at the end of the user manual. CONNECTION EXAMPLES WITH GAS BOILER SYSTEMS- THERMOSTAT PNI CT36* * The installation must be done only by authorized installer and only after consulting the user manuals, and checking the connections and their compatibility.
-
Page 15: Installation And Dimensions
3. Vaillant Ecotec Pure 4. Motan Max Optimus INSTALLATION AND DIMENSIONS The main and receiver unit can be mounted in 2 ways: 1. Table or flat surface area with the white holder inside package: 2. On the wall with wall holder plate:... - Page 16 EU Simplified Declaration of Conformity SC ONLINESHOP SRL declares that Smart thermostat PNI CT36 complies with the Directive EMC 2014/30/EU and RED 2014/53/UE and LVD 2014/35/EU. The full text of the EU declaration of conformity is available at the following Internet address: https://www.mypni.eu/products/7068/download/certifications...
