  • Page 2: Table Of Contents

    Installation, use and maintenance guide Mon Amour INDEX 1 - INTRODUCTION ..........................7 1.1 GENERAL GUIDELINES ..........................7 1.2 SAFETY GUIDELINES ............................. 7 1.3 RECOMMENDATIONS ............................. 7 1.4 GENERAL GUIDELINES ..........................9 1.5 TRANSPORTATION AND STORAGE ......................9 2 – TECHNICAL CHARACTERISTICS* ....................10 3 –...
  • Page 3 13.2 GUIDELINES FOR CORRECT INSTALLATION ..................37 13.3 TROUBLESHOOTING CAUSES-SOLUTION ....................38 14 – SPARE PARTS FOR MON AMOUR MODEL .................. 40 14.1 MAIN COMPONENTS AND THEIR POSITION 1 ..................40 14.2 MAIN COMPONENTS AND THEIR POSITION 2/3 ..................41 14.3 MAIN COMPONENTS AND THEIR POSITION 3/3 ..................
  • Page 4 Installation, use and maintenance guide Mon Amour DICHIARAZIONE DI CONFORMITA' DECLARATION OF CONFORMITY La THERMOROSSI S.P.A., VIA GRUMOLO N° 4 36011 ARSIERO (VI), sotto la sua esclusiva responsabilità DICHIARA che l’apparecchiatura descritta in appresso: DECLARES that the product: Descrizione Stufa a pellet...
  • Page 5 N° 56 Codice di identificazione unico del prodotto-tipo: Unique identification code of the product type: MON AMOUR, apparecchio per il riscaldamento domestico, senza acqua, alimentato a pellet di legno MON AMOUR, residential space heating appliance without water fired by wood pellets...
  • Page 6 Installation, use and maintenance guide Mon Amour Nel caso di una dichiarazione di prestazione relativa ad un prodotto da costruzione che rientra nell'ambito di applicazione di una norma armonizzata: In case of the declaration of performance concerning a construction product covered by a harmonised standard: L' organismo notificato TÜV Rheinland Energie und Umwelt GmbH N°...

  • Page 7: Introduction

    If the appliance is sold or transferred to another user ensure that the manual is handed over with it. Thermorossi S.p.A. retains copyright on this manual. These instructions may not be reproduced or communicated to third parties or used in any other way without the necessary authorisation.
  • Page 8 Installation, use and maintenance guide Mon Amour Before using the appliance, carefully read every section of this installation, use and maintenance guide as knowledge of the information and the regulations contained in it are essential for a correct use of the appliance.

  • Page 9: General Guidelines

    Mon Amour 1.4 GENERAL GUIDELINES Caution: the appliance must be connected to a system provided with a PE conductor (in compliance with the specifications of 2006/95/EC, concerning low voltage equipment). Before installing the appliance check the efficiency of the earth circuit of the power supply system.

  • Page 10: Technical Characteristics

    Installation, use and maintenance guide Mon Amour 2 – TECHNICAL CHARACTERISTICS* MON AMOUR Height (mm) Depth (mm) Width (mm) Weight (Kg) Firebox power Min. / Max. (KW) 3.15 / 7.69 Rated power Min. / Max. (KW) 2.82 / 6.74 Min/Max consumption (Kg/h) 0.65 / 1.59...

  • Page 11: General Description

    Mon Amour 3 – GENERAL DESCRIPTION 3.1 OPERATING TECHNOLOGY Your appliance has been built to fully satisfy all your heating and practical requirements. Top-grade components and functions managed with microprocessor technology guarantee high reliability and optimal performance.

  • Page 12: Installation

    Installation, use and maintenance guide Mon Amour 4 - INSTALLATION 4.1 APPLIANCE LOCATION Follow the general guidelines set out in paragraph 1.1 to Heat Insulating Material the letter. Above all keep in mind that the floor of the installation site must be capable of bearing the weight of the appliance added to the weight of the pellets in the tank.

  • Page 13: Mounting The Casing

    Mon Amour 4.2 MOUNTING THE CASING ATTENTION: before proceeding to mount the casing and positioning the appliance, adjust the mounting feet to the maximum height. Dettaglio X DETTAGLIO Z DETTAGLIO Y Legenda: Key: Dettaglio Detail Attach the plates A to the left and right side panels with the supplied screws B.

  • Page 14: Description Of The Controls

    Installation, use and maintenance guide Mon Amour 5 – DESCRIPTION OF THE CONTROLS The appliance, when operating, could be hot to the touch, particularly the door of the combustion chamber: take care when handling the appliance components. Your appliance has obtained the CE marking and has been made to run for at least one hour to check that it functions correctly.

  • Page 15: Description Of The Power Panel

    Mon Amour LEVEL Is used to change the rotation speed of the smoke suction unit. (See para. 5.5) THERMOCOMFORT This button is used to activate the connection with the optional handheld radio control. (See para. 5.6)

  • Page 16: Date/Time: Setting The Date And Time

    Installation, use and maintenance guide Mon Amour 5.3 DATE/TIME: SETTING THE DATE AND TIME The appliance must be energised and the I/0 switch in position “I". The current date and time can be set using the DATE/TIME function. To set the current time and date proceed as follows:...
  • Page 17 Mon Amour The following screen will appear: At this point if no further programming is required for that day go to point 5-A. If, on the other hand, you wish to program a second ON/OFF cycle for that day go to point 5-B.

  • Page 18: Level: Operating Level Setting

    Installation, use and maintenance guide Mon Amour In the event of a programmed cycle on always ensure that the brazier is clean and in the correct position. Failure to clean the brazier can reduce and/or affect the life of the spark plug as it would be subjected to high temperatures due to poor cooling.

  • Page 19: Thermocomfort: Activating The Connection With The Handheld Radio Control (Optional)

    Mon Amour To change the operating level, hold down a Scroll Button while simultaneously pressing the other Scroll Button. To set the desired level simply press the Menu Button several times until the initial screen will appear on the display.

  • Page 20: Operation Of The Handheld Radio Control Thermocomfort (Optional)

    Installation, use and maintenance guide Mon Amour 6 - OPERATION OF THE HANDHELD RADIO CONTROL THERMOCOMFORT (OPTIONAL) The Thermocomfort handheld radio control is the instrument that allows you to optimise both consumption and functions. If set in AUTO mode, the radio control detects the room temperature where it is located and automatically manages the modulation of the combustion power and the ventilation power of the appliance according to the target temperature set by the user in the radio control.

  • Page 21: Use Of The Handheld Radio Control

    Mon Amour To switch on the radio control, the following operations must be carried out: Remove the battery cover and flick the main switch to ON, as illustrated in the figure below. (This operation is only required...
  • Page 22 Installation, use and maintenance guide Mon Amour Page 22...
  • Page 23 Mon Amour MANUALprogram In the MANUAL program the room temperature thermostat of the radio control is disabled. It will therefore be possible to manually set both the ventilation power and the combustion power. To set or change the combustion power simply press the Flame Button (1), and the flame symbol on the screen will begin to flash for several seconds.
  • Page 24 Devices or parts returned for replacement become the property of Thermorossi. S.p.A. The presence of any irregular black-blue lines on the display, also present when de-energised and/or battery flat or missing, indicate that the glass screen of the display is damaged following a fall or impact: in this case the breakage is not covered by the guarantee.

  • Page 25: Use Of The Appliance

    Mon Amour 7 – USE OF THE APPLIANCE 7.1 DESCRIPTION OF THE OPERATING STAGES START: has a duration of approx. 20 minutes, during this phase the appliance is programmed to light the flame. The appliance will not accept power variations in the firebox.

  • Page 26: Room Temperature Thermostat / Chronothermostat (Not Supplied)

    230 V or lower voltages as this would seriously damage the control board, and is not covered by warranty. CAUTION: In the event of connections to the chronothermostat Thermorossi shall not be held responsible for the appliance not starting up, smoke leaks, breakage of the lighting component. The user must make sure that the brazier is always clean.
  • Page 27 Mon Amour Legenda Cronotermostato Modem Chronothermostat - modem Termostato Ambiente Room Temperature Thermostat Encoder Aspiratore fumi Smoke suction unit encoder Termocoppia fumi Smoke thermocouple Morsettiera J5 Terminal block J5 Motore coclea Screw feeder motor Pressostato...

  • Page 28: Cleaning And Maintenance

    Installation, use and maintenance guide Mon Amour 9 CLEANING AND MAINTENANCE 9.1 FOREWORD Before beginning any maintenance operation ensure that the appliance is switched OFF and disconnected from the electric power socket. Your stove, being a pellet-fuelled appliance, requires regular general controls and cleaning. This will guarantee regular operation and optimal output at all times.
  • Page 29 Mon Amour affect the correct functioning of the appliance. Any problems resulting from total or partial lack of cleaning or maintenance will immediately void the warranty. CAUTION: if the appliance remains inactive (not used for over a month) the generator, the smoke discharge tube and the flue outlet must be thoroughly cleaned and checked for any possible obstructions (e.g.

  • Page 30: Replacing The Battery Of The Remote Control

    Installation, use and maintenance guide Mon Amour Legenda: Key: FIGURA FIGURE 9.3 REPLACING THE BATTERY OF THE REMOTE CONTROL When the infrared remote control does not send out the transmission signal (the led comes not on), the battery must be replaced.

  • Page 31: Smoke Discharge Tube And Ventilation Of The Rooms

    Mon Amour 10 – SMOKE DISCHARGE TUBE AND VENTILATION OF THE ROOMS 10.1 FOREWORD Due to the frequent accidents caused by poor functioning of flue outlets installed in private dwellings, we have prepared the following paragraph to assist the installer in his inspection of the parts concerned with eliminating the gases produced by combustion.

  • Page 32: Flue Outlet / Flue System Components

    Installation, use and maintenance guide Mon Amour present and operating (for the classification see UNI 10642 and UNI 719). The connection between the appliance and the flue outlet must only receive exhaust from one heat generator. The installer must provide one or more access points on the flue outlet to check the emissions once the appliance has been installed;...

  • Page 33: Controls Prior To Installing The Appliance

    Mon Amour 10.3.3 CONTROLS PRIOR TO INSTALLING THE APPLIANCE The user must possess a certificate of conformance for the flue outlet (Ministerial Decree 22 January 2008, no. 37). The flue outlet must be built in compliance with UNI 10683.

  • Page 34: Alarms

    ATTENTION: The appearance of one of the alarms described below, does not necessarily imply a defect in the product, but simply Thermorossi S.p.A.’s intention to inform the user of the need for corrective actions in order to guarantee maximum safety, greater reliability and high performance of the appliance .

  • Page 35: Electronic Board Layout

    Mon Amour 12 – ELECTRONIC BOARD LAYOUT Legenda Cronotermostato Modem Chronothermostat - modem Termostato Ambiente Room Temperature Thermostat Termostato 95°C Thermostat 95°C Encoder Aspiratore fumi Smoke suction unit encoder Termocoppia fumi Smoke thermocouple Display Display...
  • Page 36 Installation, use and maintenance guide Mon Amour Page 36...

  • Page 37: Information For The Skilled Technician

    Mon Amour 13 - INFORMATION FOR THE SKILLED TECHNICIAN 13.1 MAIN COMPONENTS AND THEIR POSITION SMOKE PRESSURE SWITCH This is a safety switch that stops the screw feeder motor whenever necessary. The main cause for the pressure switch tripping is a blocked flue outlet or smoke exhaust pipe.

  • Page 38: Troubleshooting Causes-Solution

    Installation, use and maintenance guide Mon Amour 13.3 TROUBLESHOOTING CAUSES-SOLUTION PROBLEM POSSIBLE CAUSE SOLUTION PELLET TANK IS EMPTY CLEAN THE BRAZIER AS INDICATED IN THIS USE AND MAINTENANCE THE “NO PELLET – CLEAN BURNER” ALARM IS SHOWN ON THE DISPLAY...
  • Page 39 Mon Amour PROBLEM POSSIBLE CAUSE SOLUTION ROOM TEMPERATURE THERMOSTAT SET TOO LOW, APPLIANCE OPERATES THE APPLIANCE NEEDS TO RUN FOR MORE HOURS AT A INTERMITTENTLY HIGHER POWER; SET A HIGHER ROOM TEMPERATURE THE APPLIANCE SHOULD OPERATE FOR MORE TIME AND WITH...

  • Page 40: Spare Parts For Mon Amour Model

    70018090 - Top con vetri 70018053 - Vetro frontale Fianco Sinistro 70018052 - Vetro superiore 70018139 - bianco 70018140 - tortora 70018141 - grigio 70018142 - bordeaux 70018143 - ruggine 70018144 - nero bronze Fianco Destro 70018145 - bianco COPERCHIO COMPLETO 70018146 - tortora 70018159 - bianco 70018147 - grigio...

  • Page 41: Main Components And Their Position 1

    Mon Amour 14.2 MAIN COMPONENTS AND THEIR POSITION 2/3 Page 41...
  • Page 42 60013843 70012316 60010149 60011428 SET CORSIE COMPLETO COPERCHIO FISSO COMPLETO 60010188 70018121 60010185 70018169 Aspiratore fumi completo 70010402 60011630 60013339 CONDENSATORE 60010185 60011428 60010344 Term. 95°C 70010325 60013559 70010234 60011793 60013918 60006682 60011246 70016306 Ventilatore Completo 60005553 Griglia 60005964 Ventilatore 60010188...

  • Page 43: Key To Figures

    Mon Amour 14.4 Key to figures LEGENDA Top con vetri Top with glass Vetro frontale Front glass Vetro superiore Top glass Carter coperchio Cover guard Bianco White Grigio Grey Bordeaux Bordeaux Ruggine Rust Nero Bronze...
