Resol VBus/EnOcean Interface adapter Manual page 15

Data security
We recommend regular backups of the data stored on the device via MicroSD
card.
Disposal
• Dispose of the packaging in an environmentally sound manner.
• At the end of its working life, the product must not be disposed of as urban
waste. Old appliances must be disposed of by an authorised body in an envi-
ronmentally sound manner. Upon request we will take back your old appliances
bought from us and guarantee an environmentally sound disposal of the devices.
Description of symbols
Warnings are indicated with a warning symbol!
Signal words describe the danger that may occur, when it is not avoided.
ATTENTION means that damage to the appliance can occur.
Î It is indicated how to avoid the danger described.
Note
Notes are indicated with an information symbol.
Î Texts marked with an arrow indicate one single instruction step to be carried
out.
1. Texts marked with numbers indicate several successive instruction steps to be
carried out.
Contents
1 Technical data ................................................................................... 16
2 EnOcean wireless technology .......................................................... 17
3 Installation ......................................................................................... 17
3.1 Mounting ..................................................................................................................... 17
3.2 Electrical connection ................................................................................................ 18
4 Operation, indication elements and interfaces .............................. 18
4.1 7-segment display ...................................................................................................... 19
4.2 Set button ................................................................................................................... 19
4.3 LED ............................................................................................................................... 19
4.4 MicroSD card ............................................................................................................. 19
5 Channels and operation .................................................................... 19
5.1 Teach-in via EnOcean ............................................................................................... 19
5.2 Assigning the VBus address ................................................................................... 20
®
6 MicroSD card ..................................................................................... 20
7 Energy saving mode .......................................................................... 20
8 Firmware update ............................................................................... 20
9 Operating control LED ..................................................................... 20
10 Protocol .............................................................................................. 20
11 Reset ................................................................................................... 21
12 Overview of the 7-segment display ................................................. 21
13 Error codes......................................................................................... 21
14 Notes on conversion ......................................................................... 22
15 Teach-in devices / Accessories .......................................................... 22
15.1 FRP12-E wireless room temperature sensor ...................................................... 22
15.2 RTA12-E wireless remote control ......................................................................... 22
15.3 RCP12-E wireless room control unit ................................................................... 23
