Instruction manual
MTL fieldbus networks
MTL83xC Modbus
PC software manual
June 2021
INM MTL83xC PC Modbus Rev 4

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CROUSE-HINDS Series and is the answer not in the manual?

Questions and answers

Related Manuals for Eaton CROUSE-HINDS Series

Summary of Contents for Eaton CROUSE-HINDS Series

  • Page 1 Instruction manual June 2021 MTL fieldbus networks INM MTL83xC PC Modbus Rev 4 MTL83xC Modbus PC software manual...
  • Page 2 This page left intentionally blank INM MTL83xC PC Modbus Rev 4...

  • Page 3: Table Of Contents

    CONTENTS INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1 1 .1 PC Requirements .

  • Page 4: Introduction

    INTRODUCTION The MTL83xC is a temperature (and mV) measuring system. It consists of an MTL838C or MTL838C-MBT and one or two MTL831C modules. See the datasheet EPS830C and installation manuals INM838C and INM831C for these modules for further details. The main interface on the MTL838C which concentrates the data from the MTL831Cs is Modbus RTU (RS485).

  • Page 5: Quickstart Guide

    QUICKSTART GUIDE This quickstart guide is written for an MTL83xC system based on an MTL831C temperature input multiplexer transmitter with an MTL838C multiplexer receiver. Before the actual installation, it is recommended that new users initially set up a simple system on the bench to become familiar with the MTL83xC system. The minimum hardware required for a test system is as follows: MTL831C Analog transmitter...

  • Page 6: Background To The Mtl838C

    BACKGROUND TO THE MTL838C 3 .1 The analog-input multiplexer system The MTL838C is an analog multiplexer receiver that is used with the MTL831C hazardous area millivolt input multiplexer transmitter. The status of up to 32 analog inputs may be communicated from the hazardous area to the safe area via a data highway, comprised of a simple twisted pair - over distances up to 2000m.

  • Page 7: On-Line Configuration

    3 .3 On-line Configuration Configuring the unit via the Modbus master and the network might seem to be the simplest method at first sight, but there are a number of practical difficulties with this configuration technique. This approach means that the user must deal with a number of complex aspects which require a significant investment of the configurer’s time before they are understood fully.

  • Page 8: Interconnection Of The Mtl838C

    3 .6 Interconnection of the MTL838C The MTL838C may be connected to a Modbus host in a number of ways. Two RS485 outputs, Link 1 and Link 2, are provided on the MTL838C. As there are two outputs the unit can either be connected to a single Modbus master, with dual redundancy, or connected to two separate Modbus hosts.

  • Page 9: Slave, Transmitter And Input Addressing

    3 .8 Slave, Transmitter and Input addressing The following discusses the allocation of addresses to the slaves on the Modbus network - including the MTL838C - and the allocation of addresses for the transmitters and inputs connected to each MTL838C. 3 .8 .1 Addressing MTL838C slaves Modbus allows slave addresses in the range 1 to 247 .
  • Page 10 PC SOFTWARE INSTALLATION The MTL83xC Configuration Software is only available from the Eaton (MTL) website. Direct your browser to www.mtl-inst.com and then locate the MTL83xC product page. There will be a link on that page to download and install the software.

  • Page 11: Pc Software Installation

    SOFTWARE OPERATION This section covers the operation of the MTL83xC Configurator software. For detailed operation of the hardware, please see the relevant installation manuals. The following is the screen that appears when the software opens: Figure 2 - The MTL838C Tab This is a standard Windows application that incorporates a typical Menu system and Tabs to organize the information.

  • Page 12: Configuration Overview

    After connecting a USB cable to the MTL838C and providing it power, the Connection Status changes to: Figure 3 - Connection status This Connection Status indicates that the PC software is communicating over the USB cable with the MTL838C – both LEDs are ON and the MTL838C word is green. The MTL838C is not communicating with the MTL831Cs in the above image.

  • Page 13: The Mtl838C Tab

    5 .2 The MTL838C Tab The items on this tab allow you to configure the MTL838C. Some of these parameters affect the entire system – others only specific aspects of the MTL838C. We will cover them in detail below: 5 .2 .1 Communication Protocol Two communication protocols for the RS485 Links are supported by the MTL838C (Modbus RTU and LLMUX).

  • Page 14: Tag Name

    5 .2 .3 Tag Name This field is user defined. When properly filled in it may be used to identify this particular MTL838C in the plant. It is available via the Modbus interface as well. Up to 24 alphanumeric characters may be entered in this field. The field is blank by default.

  • Page 15: Temperature Units

    5 .2 .7 Temperature Units Select the Units that should be used to report temperature. The dropdown allows for Celsius (the default), Fahrenheit, or Kelvin. 5 .2 .8 Baud Rate (Modbus RTU only) Select the Baud rate for the two RS485 Links. 9600 is the default. 5 .2 .9 Line Frequency The line frequency where the MTL83xC system is installed should be correctly selected from this dropdown box.

  • Page 16: Alarm Relay A

    5 .2 .11 Alarm Relay A There are 10 alarm conditions that can be used to trigger the alarm relay. If multiple conditions are selected, then they are logically OR’d together. Check the checkbox of the condition(s) that you want to trigger the alarm. The gray box to the left of the checkbox indicates the way the currently connected MTL838C is configured.

  • Page 17: Alarm Relay B

    5 .2 .12 Alarm Relay B See the explanation for Alarm Relay B. The possible settings for both alarm relays are the same. However, you can set each relay differently to get different errors to trip the two relays. 5 .2 .13 Action Buttons At the bottom of the channel area, there are three (3) buttons.

  • Page 18: Input Type

    5 .3 .1 Input Type This dropdown is used to select the type of sensor that is connected to the channel. The following are the different options available. 2W Ω 3W Ω 4W Ω 2W RTD Cu50 3W RTD Cu50 4W RTD Cu50 2W RTD Cu53 3W RTD Cu53...

  • Page 19: Input Zero, Output Zero, Gain

    5 .3 .5 Input Zero, Output Zero, Gain These three fields are used to scale the reading that is made available via Modbus. These fields are normally used with non-IEEE data formats. See the chapter on SCALING in the INM838C-MBF manual for more information.

  • Page 20: Action Buttons

    5 .4 Action Buttons At the bottom of the channel area, there are three (3) buttons. The following figure (4) shows what the tab would look like when communicating with an MTL838C that has one MTL831C connected to it that has been configured with all channels as “TC, K, Temp, CJC” . Notice that no channels are connected (the Open status and high invalid reading).
  • Page 21 Figure 5 Figure 6 INM MTL83xC PC Modbus Rev 4...

  • Page 22: Input Calculator

    5 .5 Input Calculator The Input Calculator is used to assist in calculating the Input Zero, Output Zero, and Gain values. The calculator is shown below: Enter the appropriate data in the top 4 fields. As you do this and tab or move from one field to the other, the values in the gray boxes are updated.

  • Page 23: The Mtl831C #2 Tab

    5 .6 The MTL831C #2 Tab This tab functions exactly the same as the MTL831C #1 tab. The only difference is that it contains the configuration data for the #2 MTL831C. The channel numbers are different so the Modbus system can distinguish the two units. MTL831 #1 shows up as channels 1-16 and MTL831 #2 shows up as channels 17-32.

  • Page 24: The Menu

    THE MENU At the top of the MTL83xC Configurator window is a menu that contains the following items: File, Edit, Devices, and Help. Click on the menu name to drop its menu down and then click on the menu item to execute that function. The Menu items are explained below.

  • Page 25: Edit

    The default file name is “Configs.txt” . Change its name to something more meaningful and press the Save button. We recommend keeping the “ .txt” file type so the program can easily access the files. Also, although these are text files which are easily viewed and manipulated by standard Windows software, we do not recommend altering them in this manner.

  • Page 26: Devices

    6 .3 Devices The Devices menu contains functions specific to the MTL83xC devices. The first three are commands to reset the respective pieces of hardware and the fourth item launches the window allowing firmware updates of the connected devices. All three Reset functions send a command to the selected device that tells it to reset itself (firmware reset).
  • Page 27 If a unit is not connected, then the version information is blank (as is the case above with the MTL831C #2). The latest firmware will be available on the Eaton (MTL) website www .mtl-inst .com . If you suspect that the unit has become corrupted (functionally –...
  • Page 28 If any errors occur, they will be displayed at the bottom of the window. If you get an error, try again. If that is unsuccessful, contact Eaton (MTL) for assistance. Notice that update process for the MTL831C will update ALL MTL831Cs connected to the MTL838C.

  • Page 29: Help

    6 .4 Help The last menu is the Help menu. Selecting Show Help or pressing F1 opens the instruction manual for the PC software (this document). This will open the PDF document for the mode that the software is currently in (Modbus RTU, Modbus TCP , etc.).
  • Page 30 Initially the request for diagnostic data from the MTL83xC system is OFF as indicated by the green Start button and no diagnostic data (numbers) being listed. To begin receiving diagnostic data, press the Start button. It will change to a red color and data from the units will be received.
  • Page 31 There are some errors shown in the example above. This is because the MTL831C #1 was disconnected from the Data Highway and then re-connected. It is typical in this case to see a few errors. The Bad and Fragment packets received at the MTL838C are due to Data Highway transitions due to unplugging and plugging in the MTL831C #1.
  • Page 32 Modbus Errors Link 1 (or 2) Unknown function The Modbus Host sent a function code not supported by the MTL838C CRC Error A CRC error occurred on a Modbus packet. Data is put in a buffer while waiting for the UART to Cannot send –...

  • Page 33: Ethernet Module Configuration - Mtl838C-Mbt Only

    ETHERNET MODULE CONFIGURATION – MTL838C-MBT only Initially, the MTL838C-MBT is configured to get its IP address from a DHCP server. For most installations, the IP address will need to be set to a known value so that it may be easily identified on the network. The following is what the MTL838C tab looks like when the Communication Protocol is Modbus TCP: Refer to section 5.2 for information on how to work with the various fields.
  • Page 34 The Ethernet port is configured using the blue Configure Ethernet button, or with the Device/ Configure Ethernet menu item. Selecting either of these causes the screen to change to: The Ethernet port can only be configured during power up, so at this point we are being instructed to power the unit off and then back on.
  • Page 35 Notice that the module MAC address is displayed as well as some firmware version information for the Ethernet Port. After this there are four sections numbered 1, 4, 5, and 7 . This is the main menu and these are the 4 optional areas to configure. This is a text-based interface to the Ethernet Port and the menu item is selected by typing the item number.
  • Page 36 Menu option “4” contains settings for Modbus TCP . We recommend using the defaults, but they may be changed if needed for your environment. Below is a capture of the questions and options where <Enter> was pressed to accept the default for each option: As we have already said we do not recommend enabling any of the settings in the security section.
