Error Description

Device cannot be switched ON: Check the battery capacity. Connect the USB cable or
the charger and switch on the device again. Check that the battery is properly charged (an
indicator light illuminates RED).
Device does not play: Check that the USB flash memory or the MicroSD card is formatted
in Fat32 and the songs have MP3 format.

Technical specifications

Flash memory
Ports
Power supply
Charging
process
Line-IN / 5V
Loud Speaker
ON / OFF
(Power switch)

Package Contents:

Meas device:

Security and Disposal Hints for Batteries

Hold children off batteries. When a child swallowed a battery go to a doctors place or bring the child into a hospital promptly! Look for the
right polarity (+) and (▬) of batteries! Always change all batteries, never use old and new batteries or batteries of different types together.
Never short batteries. Do NOT open, deform or load up batteries! There is a risk of injury by battery leakage fluid! NEVER throw
batteries into fire! There is a risk of explosion! Take out exhausted batteries from the device and take out batteries from the device when
its not used over a longer period of time.

Hints for Environment Protection

Packages materials are raw materials and can be recycled. Separate the packages by types and put them to an
adequate recycling on behalf of the environment. More detailed information you get from your official civil service. Do not
disposal old devices into the domestic waste. Disposal old / defective devices professionally! The environment will be
grateful for that. Do not disposal batteries into the domestic waste. Disposal old / empty / defective batteries
professionally! The environment will be more than grateful for that.
Cleaning: Protect the device from contamination and pollution. Only clean the device with soft cloth or drapery, avoid using rough or
coarse-grained materials. Do NOT use solvents or other aggressive cleaner. Wipe the device after cleaning accurately.
Important Notice: Should battery fluid leak from a battery, wipe the battery-case with a soft cloth dry.
MicroSD card (up to 32GB)
USB port (up to 32GB) and Port for 3.5mm jack cable
Built-in rechargeable Lithium battery 600mAh
Battery charging time ~2 hours
Battery playing time (with SD card) ~8 – 9 hours at medium volume
Battery playing time (with USB) ~4 – 5 hours at medium volume
AC adapter* (DC-5V, *not included)
When power OFF, LED turns red while charging.
When charging is completed, LED turns off.
When power ON, LED turns pink while charging.
When power ON but no charging process, LED turns to blue colour.
USB power supply, Audio input
1x 1.77" (external Ø 45mm) magnetic resistant 4 Ohm
Signal / Noise Ratio: ≥80dB
Output: RMS3W THD = 10%
Frequency response: 150 – 18000Hz (±3dB)
ON button: switch to ON, the device is ready for using
OFF button: switch to OFF, the device is turned off
Mini MusicMan
Supporting loop for the hand (to fix on device), User manual
50 x 50 x 50mm
®
Soundstation, Cable USB/Audio/3.5mm Jack,
Weight device: 117g
