MusicMan
The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that this device,
to which this user manual belongs, complies with the essential requirements of the standards
referred to the Directive RED 2014/53/EU. The Declaration of Conformity you find here:
www.technaxx.de/ (in bar at the bottom "Konformitätserklärung"). Before using the device
Service phone No. for technical support: 01805 012643 (14 cent/minute from German fixed-
line and 42 cent/minute from mobile networks). Free Email: support@technaxx.de
This device has a rechargeable battery. It must be fully charged before first use.
NOTE: Charge the battery of the device every 2–3 month if it is not used!
WARNING: Do not turn the volume too high – hearing loss might be the result
Features
Mobile stereo wide range speaker system with display for MP3/4, CD/DVD,
Smartphone, iPad, iPod, PSP, PC/Notebook, with integrated MP3 player for USB
flash disks and MicroSD cards up to 32GB
Built-in stereo FM radio and Line-IN/AUX
Plays all songs in WMA, WAV and MP3 format
Lightweight durable aluminium housing
Several power supply options: rechargeable and replaceable battery, computer
USB or AC adapter* (*not included)
Ideal to use at home or for traveling, easiest installation, excellent sound quality
Charging of the battery
Plug in the USB cable* (* included) into the DC input of DC-5V of the speaker. Then
connect the USB port to the USB slot of PC or other USB slot of chargers. Then the
LED shines RED. The LED will shine RED until the speaker is fully charged, and it
will turn off when the speaker is fully charged. (Recommendation: turn OFF the
speaker while charging. When it is working, it will take a longer time to get it fully
charged.) Please always fully upload the battery. NOTE: Should be repeatedly
shown on the display an hourglass, then you have to change the battery.
Silver power button ON / OFF: press it to turn the device ON or OFF
VOL+ / VOL– : press for volume adjustment
: press short to move left / right, or choose last / next song
MENU: press short to enter a sub-menu or confirm
LOUDSPEAKERS: press long the MENU button to turn the speaker ON or OFF
Action
Short press
Long press
Select
®
MA Display * User Manual
the first time, read the user manual carefully.
Basic operations
Key pressing time less than 2 seconds
Key pressing time more than 2 seconds
Press the key and hold it pressed
Advertisement
Related Manuals for Technaxx MusicMan MA Display
Summary of Contents for Technaxx MusicMan MA Display
- Page 1 MusicMan MA Display * User Manual The manufacturer Technaxx Deutschland GmbH & Co.KG hereby declares that this device, to which this user manual belongs, complies with the essential requirements of the standards referred to the Directive RED 2014/53/EU. The Declaration of Conformity you find here: www.technaxx.de/ (in bar at the bottom “Konformitätserklärung”).
-
Page 2: Functional Applications
Note: Unless otherwise specified, “press” in this manual means “short press”. Time: Turn on to enter MENU. Insert card/USB to enter MUSIC play. Insert audio cable to choose Line–IN play. Main Interface (5 applications): Calendar, Music, Line–IN, FM, System Settings Press the MENU key to access the main menu. - Page 3 Insert a MicroSD memory card or USB flash drive Before MP3 music tracks are copied on MicroSD card or USB flash drive, both memory media have to be formated under Windows to FAT32. The golden contacts must be directed upwards and forwards. Always do the installing and removing of the MicroSD card with care, otherwise the contacts of the device and/or the MircoSD card may be damaged.
- Page 4 Submenu 2 In the playing status press MENU to enter the following submenu: FM Radio, Circle mode, EQ settings, Back & Exit Circle mode: select “Circle mode” and select the desired repeat mode with the keys and confirm it with the MENU key. Circle Mode Icon Description Normal...
- Page 5 Line-In – function and operation: In the main menu interface insert the Line-In cable to turn into LINE-IN play. Port for antenna and headphones: Music can be heard via USB stick, via MicroSD card or via radio, either through the speakers of the MusicMan or with headphones.
- Page 6 Long press searchs automatically backward or forward stations. It stopps after receiving a radio broadcast. When the program already is saved, the interface shows the serial number stored. If not saved, you need to save the program manually. When saving is finished, press to switch and play among the saved stations.
- Page 7 Backlight: Press to adjust the backlight parameter. Press MENU to confirm and exit. If the display shows „00“, the background is always bright. If a different value is shown (01–15), the background light goes off. Contrast: Press to adjust the backlight parameter.
-
Page 8: Technical Specifications
Input power (0.4-1.0 A) from USB or AC adapter* Music format MP3 / WMA / WAV –5°C up to +50°C Temperature Weight / Dimensions 220 g / 5,0 x 5,3 x 16,5 cm MusicMan MA Display, USB/Power/Audio cable, Package Contents User manual... - Page 9 Important Notice: Should battery fluid leak from a battery, wipe the battery case with a soft cloth dry. Distributor: Technaxx Deutschland GmbH & Co.KG, Kruppstr. 105, 60388 Frankfurt a.M., Germany Keep this user manual for future reference or product sharing carefully. Do the same with the original accessories for this product.
