3. TECHNICAL DATA TABLE - FRYERS

BURNERS
MODEL
No. x kW
60/30 FRG 2 x 3,4
60/60 FRG 4 x 3,4
NOZZLE FOR PILOT BURNERS
3.1

GAS CHARACTERISTICS

The data relative to power and consumption refer to the following types of gas:
TYPE OF GAS
G20 (methane gas) CH
G30 (butane) C H
4 10
G31 (propane) C H
3
G25 (G20L – DE)
G25 (aardgas NL)
When installing the appliances, the gas supply pressures must be those given above in order to have maximum burner efficiency.
Pressures mbar: 1 millibar = 1 mbar = 10 mm (water column millimetres)
Power: 1 kW = 860 kcal = 3.6 MJ = 3412 BTU
CAPACITY TOTAL
TUB POWER
L kW
8
6.8
8+8
13.6
NET HEAT VALUE
(NHV)
9.45 kW m³/h
4
12.68 kW/kg
12.87 kW/kg
8
8.12 kW m³/h
8.12 kW m³/h
USER'S MANUAL
TOTAL GAS
CONSUMPTION
LPG METHANE
G30 – G31
G20
kg/h m³/h
0,528 0,720
1,056 1,440
PRESSURE SUPPLY
mbar
20
30
37
20
25
DIAMETER OF NOZZLES IN
HUNDREDTHS OF A MILLIMETRE
LPG METHANE
G30 – G31
G20
28/30 mbar 20 mbar
95L 140L
95L 140L
30 51
mm water
200
300
370
200
250
